Sun Seeker e-DELTA - Handlebar and Stem Installation; Seat Frame and Strut Installation

7
Assembly Guide
Handlebar & Stem Installation
1.Install#7HandlebarandStemAssemblyintofork.SeeFigureF.
Seat Frame Assembly and Strut Installation
1.Install2#16UpperSeatStrutsand1/2moonnylonwashersto#12SeatFrametabswiththeprovided
hardware.SeeFigureG.
2.Insert2#17LowerSeatStrutsinto#16UpperSeatStrutsanduse2#18SeatStrutPinstosecurethe
struts.
3.Install#23SeatMountBracketusing#13M8x90mmBoltthrough#12SeatFrametabsandsecurewith
nutprovided.SeeFigureH.
F
G H
Tightento10Nm
(87In.Lbs)
Lubricate
stem&
wedge
before
inserting
10
18
16
17
12
12
13
23
