Sun Seeker e-DELTA - Rear Derailleur Installation

8
Assembly Guide
Seat Frame Assembly and Strut Installation (continued)
4.Install#23SeatMountBracketonto#1MainFrameandsecurewith#14QuickReleaseSeatPin.
SeeFigureI.
5.Install2#16LowerSeatStrutsontotherearframemounttabsonthe#2RearUnitAssemblyandsecure
withtheprovidedhardware.
Rear Derailleur Installation
1.Install#20RearDerailleurontothe#2RearUnitAssemblyderailleurtabandsecurewiththeprovided
hardware.
SeeFigureJ.
I
J
Tightento8-9Nm
(70-85ln.Lbs)
