our current supplier. The slides depicted are side-
mounted units and are manufactured by:
Crenlo, Inc. – Emcor Products
“SLIM – SLIDE
®
” (Product Line)
The current slides are being phased out and will
be replaced by units manufactured by:
General Devices Co., Inc.
“CHASSIS TRAK
®
” (Product Line)
The new slides, however, mount “Front-to-Back”
and use the Rack’s Front and Rear mounting
flanges instead of the side rails. This transition is
pending.
NOTE
The RT-9000C Transceiver (and its predecessors) is
approximately 1 inch less than four (4) Rack Units (7.00
inches) high. When the Front Panel Shroud Assembly is
installed, the combination of the transceiver and shroud
assembly occupies exactly four Rack Units. The
“brackets, trim strips, etc.” shown in the drawing are
components associated with the Shroud Assembly.
Figure 8.2 RT-9000C Rack Mounting Details
