RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-13
RT-9000C
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
PC Assembly, Synthesizer, Rev. H
8076060095
C1 CAP. .1UF, 50V, X7R, 20% 1013040031
C2 CAP. .1UF, 50V, X7R, 20% 1013040031
C3 CAP. .1UF, 50V, X7R, 20% 1013040031
C4 CAP. .1UF, 50V, X7R, 20% 1013040031
C5 CAP. 390PF, NPO, 5%, 200V 1013903919
C6 CAP. 82PF, NPO, 5%, 200V 1013908201
C7 CAP. 470PF, NPO, 5%, 200V 1013904711
C8 CAP. 270PF, NPO, 5%, 200V 1013902718
C9 CAP. 390PF, NPO, 5%, 200V 1013903919
C10 CAP. 560PF, NPO, 5%, 200V 1013905610
C11 CAP. 270PF, NPO, 5%, 200V 1013902718
C12 CAP. 560PF, NPO, 5%, 200V 1013905610
C13 CAP. 56PF, NPO, 5%, 200V 1013905601
C15 CAP. 56PF, NPO, 5%, 200V 1013905601
C16 CAP. 560PF, NPO, 5%, 200V 1013905610
C17 CAP. .01UF, 50V, X7R, 20% 1013030036
C18 CAP. .01UF, 50V, X7R, 20% 1013030036
C19 CAP. .1UF, 50V, X7R, 20% 1013040031
C20 CAP. .01UF, 50V, X7R, 20% 1013030036
C21 CAP. .01UF, 50V, X7R, 20% 1013030036
C22 CAP. .01UF, 50V, X7R, 20% 1013030036
C23 CAP. 10UF, 20V TANT 1007290005
C24 CAP. 56PF, NPO, 5%, 200V 1013905601
C25 CAP. 390PF, NPO, 5%, 200V 1013903919
C26 CAP. 10UF, 20V TANT 1007290005
C102 CAP. 6.8UF, 25V TANT 1005050031
C103 CAP. .1UF, 50V, X7R, 20% 1013040031
C104 CAP. .01UF, 50V, X7R, 20% 1013030036
C105 CAP. 6.8UF, 25V TANT 1005050031
C106 CAP. .1UF, 50V, X7R, 20% 1013040031
C107 CAP. .1UF, 50V, X7R, 20% 1013040031
C108 CAP. 0.1UF, 50V, X7R 1011180014
C109 CAP. 0.01UF, 50V, X7R, 20% 0281730008
C110 CAP. 0.001UF, 100V, X7R, 20% 0281630003
C111 CAP. 10PF, 1000V, N750 5% 0250480000
C112 CAP. 7PF, 500V, N1500 0295250003
C113 CAP. 7PF, 500V, N1500 0295250003
C114 CAP. 7PF, 500V, N1500 0295250003
C115 CAP. 470PF, NPO, 5%, 200V 1013904711
C116 CAP. 470PF, NPO, 5%, 200V 1013904711
C117 CAP. 470PF, NPO, 5%, 200V 1013904711
C118 CAP. 470PF, NPO, 5%, 200V 1013904711
C119 CAP. .001UF, 50V, X7R, 20% 1013020031
C120 CAP. .001UF, 50V, X7R, 20% 1013020031
C121 CAP. .001UF, 50V, X7R, 20% 1013020031
C122 CAP. .001UF, 50V, X7R, 20% 1013020031
C123 CAP. 47PF, NPO, 5%, 200V 1013904702
C124 CAP. 33PF, NPO, 5%, 200V 1013903307 C
C125 CAP. 68PF, NPO, 5%, 200V 1013906802
C126 CAP. 39PF, NPO, 5%, 200V 1013903901
C127 CAP. 68PF, NPO, 5%, 200V 1013906802
C128 CAP. 56PF, NPO, 5%, 200V 1013905601
C129 CAP. 47PF, NPO, 5%, 200V 1013904702 C
C130 CAP. 27PF, NPO, 5%, 200V 1013902700 C
C131 CAP. 100PF, NPO, 5%, 200V 1013901011
C132 CAP. 100PF, NPO, 5%, 200V 1013901011
C133 CAP. 100PF, NPO, 5%, 200V 1013901011
C134 CAP. 100PF, NPO, 5%, 200V 1013901011
C135 CAP. .001UF, 50V, X7R, 20% 1013020031
C136
CAP. .001UF, 50V, X7R, 20%
1013020031
C137 CAP. .001UF, 50V, X7R, 20% 1013020031
C138 CAP. .001UF, 50V, X7R, 20% 1013020031
C139 CAP. 10PF, NPO, 5%, 200V 1013901002
C140 CAP. 10PF, NPO, 5%, 200V 1013901002
C141 CAP. 10PF, NPO, 5%, 200V 1013901002
C142 CAP. 10PF, NPO, 5%, 200V 1013901002
C143 CAP. 100PF, NPO, 5%, 200V 1013901011
C144 CAP. 100PF, NPO, 5%, 200V 1013901011
C145 CAP. 100PF, NPO, 5%, 200V 1013901011
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 1 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C146
CAP. 100PF, NPO, 5%, 200V
1013901011
C147 CAP. .001UF, 50V, X7R, 20% 1013020031
C148 CAP. .001UF, 50V, X7R, 20% 1013020031
C149 CAP. .001UF, 50V, X7R, 20% 1013020031
C150 CAP. 470PF, NPO, 5%, 200V 1013904711
C151 CAP. 470PF, NPO, 5%, 200V 1013904711
C152 CAP. .001UF, 50V, X7R, 20% 1013020031
C153 CAP. 470PF, NPO, 5%, 200V 1013904711
C154 CAP. 470PF, NPO, 5%, 200V 1013904711
C155 CAP. .1UF, 50V, X7R, 20% 1013040031
C156 CAP. .1UF, 50V, X7R, 20% 1013040031
C157 CAP. .001UF, 50V, X7R, 20% 1013020031
C158 CAP. 33PF, NPO, 5%, 200V 1013903307
C159 CAP. 7PF, 500V, N1500 0295250003
C160 CAP. 7PF, 500V, N1500 0295250003
C161 CAP. 10UF, 20V TANT 1007290005
C162 CAP. .01UF, 50V, X7R, 20% 1013030036
C163 CAP. .001UF, 50V, X7R, 20% 1013020031
C164 CAP. .001UF, 50V, X7R, 20% 1013020031
C165 CAP. .001UF, 50V, X7R, 20% 1013020031
C166 CAP. .001UF, 50V, X7R, 20% 1013020031
C167 CAP. 1UF, 35V TANT 0281660000
C168 CAP. 1UF, 35V TANT 0281660000
C169 CAP. 1UF, 35V TANT 0281660000
C170 CAP. 1UF, 35V TANT 0281660000
C171 CAP. .001UF, 50V, X7R, 20% 1013020031
C172 CAP. .001UF, 50V, X7R, 20% 1013020031
C173 CAP. 0.01UF, 50V, X7R, 20% 0281730008
C174 CAP. 15UF, 35V TANT 0282240004
C176 CAP. 39PF, NPO, 5%, 200V 1013903901
C177 CAP. 22PF, NPO, 5%, 200V 1013902203
C179 CAP. 10PF, NPO, 5%, 200V 1013901002
C180 CAP. 56PF, NPO, 5%, 200V 1013905601 C
C181 CAP. 39PF, NPO, 5%, 200V 1013903901 C
C182 CAP. 33PF, NPO, 5%, 200V 1013903307
C183 CAP. 33PF, NPO, 5%, 200V 1013903307 C
C184 CAP. 10UF, 20V TANT 1007290005
C203 CAP. .1UF, 50V, X7R, 20% 1013040031
C204 CAP. .1UF, 50V, X7R, 20% 1013040031
C205 CAP. .1UF, 50V, X7R, 20% 1013040031
C206 CAP. .1UF, 50V, X7R, 20% 1013040031
C207 CAP. .1UF, 50V, X7R, 20% 1013040031
C208 CAP. .1UF, 50V, X7R, 20% 1013040031
C209 CAP. .1UF, 50V, X7R, 20% 1013040031
C210 CAP. 560PF, NPO, 5%, 200V 1013905610
C211 CAP. 5600PF, 200V, NPO, 5% 1012905624
C212 CAP. 5600PF, 200V, NPO, 5% 1012905624
C213 CAP. 5600PF, 200V, NPO, 5% 1012905624
C214 CAP. 5600PF, 200V, NPO, 5% 1012905624
C215 CAP. .1UF, 50V, X7R, 20% 1013040031
C217
CAP. .1UF, 50V, X7R, 20%
1013040031
C218 CAP. .01UF, 50V, X7R, 20% 1013030036
C219 CAP. .01UF, 50V, X7R, 20% 1013030036
C220 CAP. 270PF, NPO, 5%, 200V 1013902718
C221 CAP. 1000PF, NPO, 5%, 200V 1013901029
C222 CAP. 1000PF, NPO, 5%, 200V 1013901029
C223 CAP. 10UF, 20V TANT 1007290005
C224 CAP. .01UF, 50V, X7R, 20% 1013030036
C225 CAP. .01UF, 50V, X7R, 20% 1013030036
C226 CAP. 10UF, 20V TANT 1007290005
C304 CAP. .001UF, 50V, X7R, 20% 1013020031
C305 CAP. .1UF, 50V, X7R, 20% 1013040031
C306 CAP. 100PF, NPO, 5%, 200V 1013901011
C307 CAP. .1UF, 50V, X7R, 20% 1013040031
C308 CAP. 0.01UF, 50V, X7R, 20% 0281730008
C309 CAP. 0.1UF, 50V, X7R 1011180014
C310 CAP. 560PF, NPO, 5%, 200V 1013905610 D
C311 CAP. .001UF, 50V, X7R, 20% 1013020031
C312 CAP. 27PF, 500V, N220, 5% 0295130008
C313 CAP. 100PF, NPO, 5%, 200V 1013901011
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 2 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C314
CAP. 33PF, NPO, 5%, 200V
1013903307 C,D
C315 CAP. 0.001UF, 100V, X7R, 20% 0281630003
C316 CAP. 470PF, NPO, 5%, 200V 1013904711
C317 CAP. .001UF, 50V, X7R, 20% 1013020031
C318 CAP. .01UF, 50V, X7R, 20% 1013030036
C319 CAP. 10UF, 20V TANT 1007290005
C320 CAP. 100PF, NPO, 5%, 200V 1013901011
C321 CAP. 10PF, NPO, 5%, 200V 1013901002
C322 CAP. 0.01UF, 50V, X7R, 20% 0281730008
C323 CAP. .001UF, 50V, X7R, 20% 1013020031
C324 CAP. .01UF, 50V, X7R, 20% 1013030036
C325 CAP. 15UF, 35V TANT 0282240004
C328 CAP. .1UF, 50V, X7R, 20% 1013040031
C329 CAP. .1UF, 50V, X7R, 20% 1013040031
C330 CAP. .1UF, 50V, X7R, 20% 1013040031
C331 CAP. .1UF, 50V, X7R, 20% 1013040031
C332 CAP. 10UF, 20V TANT 1007290005
C333 CAP. .1UF, 50V, X7R, 20% 1013040031
C334 CAP. .1UF, 50V, X7R, 20% 1013040031
C336 CAP. .1UF, 50V, X7R, 20% 1013040031
C337 CAP. .1UF, 50V, X7R, 20% 1013040031
C338 CAP. 6.8UF, 25V TANT 1005050031
C339 CAP. 33PF, NPO, 5%, 200V 1013903307 D
C340 CAP. .001UF, 50V, X7R, 20% 1013020031
C341 CAP. .001UF, 50V, X7R, 20% 1013020031
C342 CAP. .001UF, 50V, X7R, 20% 1013020031
C343 CAP. .001UF, 50V, X7R, 20% 1013020031
C344 CAP. .001UF, 50V, X7R, 20% 1013020031
C346 CAP. 10UF, 20V TANT 1007290005
C401 CAP. 10UF, 20V TANT 1007290005
C402 CAP. .1UF, 50V, X7R, 20% 1013040031
C403 CAP. .01UF, 50V, X7R, 20% 1013030036
C404 CAP. 1UF, 35V TANT 0281660000
C405 CAP. 10UF, 20V TANT 1007290005
C407 CAP. 15UF, 35V TANT 0282240004
C408 CAP. 6.8UF, 25V TANT 1005050031
C409 CAP. 6.8UF, 25V TANT 1005050031
C410 CAP. .1UF, 50V, X7R, 20% 1013040031
C411 CAP. .01UF, 50V, X7R, 20% 1013030036
C412 CAP. 6.8UF, 25V TANT 1005050031
C413
CAP. .1UF, 50V, X7R, 20%
1013040031
C414 CAP. 39PF, NPO, 5%, 200V 1013903901
C415 CAP. 100PF, NPO, 5%, 200V 1013901011
C416 CAP. 680PF, NPO, 5%, 200V 1013906811
C417 CAP. 39PF, NPO, 5%, 200V 1013903901
C418 CAP. .01UF, 50V, X7R, 20% 1013030036
C419 CAP. 39PF, NPO, 5%, 200V 1013903901
C420 CAP. 100PF, NPO, 5%, 200V 1013901011
C421 CAP. 680PF, NPO, 5%, 200V 1013906811
C422 CAP. 39PF, NPO, 5%, 200V 1013903901
C423 CAP. .01UF, 50V, X7R, 20% 1013030036
C424 CAP. 15PF, NPO, 5%, 200V 1013901509
C425 CAP. 15PF, NPO, 5%, 200V 1013901509
C426 CAP. .01UF, 50V, X7R, 20% 1013030036
C427 CAP. 100PF, NPO, 5%, 200V 1013901011
C428 CAP. 68PF, NPO, 5%, 200V 1013906802
C429 CAP. 100PF, NPO, 5%, 200V 1013901011
C430 CAP. 68PF, NPO, 5%, 200V 1013906802
C431 CAP. .01UF, 50V, X7R, 20% 1013030036
C432 CAP. 12PF, 200V NPO 5% 1012901203 E
C433 CAP. 6.8PF, 200V, NPO,+/- .5PF 1012906892 E
CR104 DIODE, VARICAP MV209 1007060018
CR105 DIODE, VARICAP MV209 1007060018
CR106 DIODE, VARICAP MV209 1007060018
CR107 DIODE, VARICAP MV209 1007060018
CR108 DIODE, VARICAP MV209 1007060018
CR109 DIODE, VARICAP MV209 1007060018
CR110 DIODE, VARICAP MV209 1007060018
CR111 DIODE, VARICAP MV209 1007060018
CR113 DIODE, VARICAP MV209 1007060018
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 3 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
CR114 DIODE, VARICAP MV209 1007060018
CR116 DIODE, VARICAP MV209 1007060018
CR117 DIODE, VARICAP MV209 1007060018
CR118 DIODE, VARICAP MV209 1007060018
CR119 DIODE, VARICAP MV209 1007060018
CR120 DIODE, VARICAP MV209 1007060018
CR121 DIODE, VARICAP MV209 1007060018
CR122 DIODE, SCHOTTKY HSMS-2820 1013160037
CR123 DIODE, SCHOTTKY HSMS-2820 1013160037
CR124 DIODE, SCHOTTKY HSMS-2820 1013160037
CR125 DIODE, SCHOTTKY HSMS-2820 1013160037
CR126 DIODE, PIN HSMP-3820 1013170032
CR127 DIODE, PIN HSMP-3820 1013170032
CR128 DIODE, PIN HSMP-3820 1013170032
CR129 DIODE, PIN HSMP-3820 1013170032
CR130 DIODE, SIGNAL, SIL MMBD914 1013150031
CR201 DIODE, LED, RED 550-2405 1008480029
CR202 DIODE, LED, RED 550-2405 1008480029
CR203 DIODE, LED, RED 550-2405 1008480029
CR204 DIODE, LED, RED 550-2405 1008480029
CR205 DIODE, LED, RED 550-2405 1008480029
CR303 DIODE, SIGNAL, SIL MMBD914 1013150031
CR304 DIODE, VARICAP MV209 1007060018
CR305 DIODE, VARICAP MV209 1007060018
CR306 DIODE, SIGNAL, SIL MMBD914 1013150031
CR308 DIODE, SCHOTTKY HSMS-2820 1013160037
FL1 FILTER, CRYSTAL, 10.7MHZ 1012950018
FL1 FILTER, CRYSTAL, 10.7MHZ 1012950018
FL201 FILTER, CERAMIC, 455KHZ 1012590020
J201 CONNECTOR, HEADER, 10 PIN MALE 1010800027
L1
INDUCTOR, MOLDED, 0.68UH, 5%
0651770009
L2 INDUCTOR, MOLDED, 0.39UH, 5% 0649770005
L3 INDUCTOR, MOLDED, 0.47UH, 5% 0648500004
L4 INDUCTOR, VAR, 2.6-3.8UH 1012560023
L5 INDUCTOR, VAR, 2.6-3.8UH 1012560023
L6 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L7 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L101 INDUCTOR, VAR, .38-.42UH 1013000013
L102 INDUCTOR, VAR, .38-.42UH 1013000013
L103 INDUCTOR, VAR, .38-.42UH 1013000013
L104 INDUCTOR, VAR, .38-.42UH 1013000013
L105 INDUCTOR, VAR, .38-.42UH 1013000013
L106 INDUCTOR, VAR, .38-.42UH 1013000013
L107 INDUCTOR, MOLDED, 8.2UH, 5% 0648240002
L108 INDUCTOR, MOLDED, 8.2UH, 5% 0648240002
L109 INDUCTOR, MOLDED, 8.2UH, 5% 0648240002
L110 INDUCTOR, MOLDED, 8.2UH, 5% 0648240002
L111 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L112 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L113 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L114 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L201 INDUCTOR, SMT, 150UH, 5% 1013701518
L202 INDUCTOR, SMT, 15UH, 5% 1013701500
L203 INDUCTOR, SMT, 15UH, 5% 1013701500
L206 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L207 INDUCTOR, SMT, 150UH, 5% 1013701518
L208 INDUCTOR, SMT, 150UH, 5% 1013701518
L209 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L301 INDUCTOR, VAR, .38-.42UH 1013000013
L302 INDUCTOR, VAR, .38-.42UH 1013000013
L303 INDUCTOR, MOLDED, 8.2UH, 5% 0648240002
L304 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L306 INDUCTOR, MOLDED, 1.0UH, 5% 0648360008 G
L307 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L308 INDUCTOR, MOLDED, 0.68UH, 5% 0651770009
L401 INDUCTOR, SMT, 150UH, 5% 1013701518
L403 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L404 INDUCTOR, SMT, .10UH, 5% 1013701089
L405 INDUCTOR, SMT, .15UH, 5% 1013701585
L406 INDUCTOR, SMT, 1.0UH, 5% 1013701097
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 4 of 7
Figure 8.7 1A2A2 Synthesizer Assembly - DDS
Version – Parts List (Sheet 1 of 2)
To Next Page
Loading...
