RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-14
RT-9000C
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
L407 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L408 INDUCTOR, SMT, .10UH, 5% 1013701089
L409 INDUCTOR, SMT, .15UH, 5% 1013701585
L410 INDUCTOR, SMT, 1.0UH, 5% 1013701097
L411 INDUCTOR, SMT, 150UH, 5% 1013701518
L412 INDUCTOR, MOLDED, 68UH, 5% 0651650003 E
P3 CONNECTOR, RF, RIGHT ANGLE 1010730002
P4 CONNECTOR, RF, RIGHT ANGLE 1010730002
Q101 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q107 TRANSISTOR, PNP MMBT4126 1013100034
Q108 TRANSISTOR, PNP MMBT4126 1013100034
Q109 TRANSISTOR, PNP MMBT4126 1013100034
Q110 TRANSISTOR, PNP MMBT4126 1013100034
Q111 TRANSISTOR, N-CH, FET U310 1007050039
Q112 TRANSISTOR, N-CH, FET U310 1007050039
Q113 TRANSISTOR, N-CH, FET U310 1007050039
Q114 TRANSISTOR, N-CH, FET U310 1007050039
Q202 TRANSISTOR, NPN MMBT4124 1013090039
Q204 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q302 TRANSISTOR, N-CH, FET U310 1007050039
Q304
TRANSISTOR, N-CH, FET 2N7002
1013080033
Q305 TRANSISTOR, N-CH, FET 2N7002 1013080033 G
R1 RESISTOR 3.9K, 5%, 1/8W 1013803922
R2 RESISTOR 3.9K, 5%, 1/8W 1013803922
R3 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R4 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R5 RESISTOR 220, 10%, 1/2W CF 0172850002
R6 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R7 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R8 RESISTOR 220, 10%, 1/2W CF 0172850002
R104 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R105 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R106 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R107 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R108 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R109 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R110 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R111 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R112 RESISTOR 680, 5%, 1/8W SMT 1206 1013806816 C
R113 RESISTOR 680, 5%, 1/8W SMT 1206 1013806816 C
R114 RESISTOR 1.5K, 5%, 1/8W SMT 1206 1013801521 C
R115 RESISTOR 6.8K, 5%, 1/8W 1013806824
R116 RESISTOR 6.8K, 5%, 1/8W 1013806824
R117 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R118 RESISTOR 47K, 5%, 1/8W 1013804732
R119 RESISTOR 47K, 5%, 1/8W 1013804732
R120 RESISTOR 47K, 5%, 1/8W 1013804732
R121 RESISTOR 47K, 5%, 1/8W 1013804732
R122 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R123 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R124 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R125 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R126 RESISTOR 1.8K, 5%, 1/8W 1013801822
R127 RESISTOR 1.8K, 5%, 1/8W 1013801822
R128 RESISTOR 1.8K, 5%, 1/8W 1013801822
R129 RESISTOR 1.8K, 5%, 1/8W 1013801822
R130 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R131 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R132 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R133 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R134 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R135 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R136 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R137 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R138 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R139 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R140 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R141 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R142 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R143 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 5 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R144 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R145 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R146 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R147 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R148 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R149 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R150 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R151 RESISTOR 220, 10%, 1/2W CF 0172850002
R152 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R153 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R154
RESISTOR 10K, 5%, 1/8W SMT 1206
1013801032
R155 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R156 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R157 RESISTOR 150, 10%, 1/2W CF 1010400037
R158 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R159 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R160 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R201 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R202 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R203 RESISTOR 3.3K, 5%, 1/8W 1013803329
R204 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R205 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R206 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R207 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R208 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R209 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R210 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R211 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R212 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R219 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R220 RESISTOR 330, 5%, 1/8W SMT 1206 1013803311
R221 RESISTOR 3.9K, 5%, 1/8W 1013803922
R222 RESISTOR 3.9K, 5%, 1/8W 1013803922
R225 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R226 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R227 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R228 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R229 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R230 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R231 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R232 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R233 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R305 RESISTOR 330, 5%, 1/8W SMT 1206 1013803311
R306 RESISTOR 330, 5%, 1/8W SMT 1206 1013803311
R307 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R308 RESISTOR 2.7K, 5%, 1/8W SMT 1206 1013802721 D
R309 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R310 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R311 RESISTOR 6.8K, 5%, 1/8W 1013806824
R312 RESISTOR 47K, 5%, 1/8W 1013804732
R313 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R314 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R315 RESISTOR 6.8K, 5%, 1/8W 1013806824
R316 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R317 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R318 RESISTOR 220, 10%, 1/2W CF 0172850002
R319 RESISTOR 150, 10%, 1/2W CF 1010400037
R320 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R321 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R322 RESISTOR 51, 5%, 1/8W SMT 1206 1013805101
R324 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R325 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R326 RESISTOR 1K, 5%, 1/8W SMT 1206 1013801024
R327 RESISTOR 470, 10%, 1/2W CF 0173900003
R329 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R330 RESISTOR 18, 5%, 1/8W SMT 1206 1013801806
R331 RESISTOR 270, 5%, 1/8W SMT1206 1013802713
R333 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
R401 RESISTOR 1.8K, 5%, 1/8W 1013801822
R402 RESISTOR 15K, 1%, 1/8W MF 1004050003
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 6 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R403
RESISTOR 3320, 1%, 1/8W
1003050000
R404 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041 E
R405 RESISTOR 10K, 5%, 1/8W SMT 1206 1013801032
R406 RESISTOR 10, 5%, 1/8W SMT 1206 1013801008
R407 RESISTOR 220, 10%, 1/2W CF 0172850002
R408 RESISTOR 100K, 5%, 1/8W SMT 1206 1013801041
R409 RESISTOR 100, 5%, 1/8W SMT 1206 1013801016
T101 TRANSFORMER, RF, 4:1 T4-1X65 MINIC 1010860003
T301 TRANSFORMER, RF, 4:1 T4-1X65 MINIC 1010860003
TP1 TEST POINT, RED 1011130033
TP2 TEST POINT, RED 1011130033
TP21 TEST POINT, RED 1011130033
TP101 TEST POINT, RED 1011130033
TP301 TEST POINT, RED 1011130033
TP302 TEST POINT, RED 1011130033
U1 IC. DIGITAL, DDS AD9850BRS 1013000030
U2 IC. LINEAR MAR-3 MINI CIRCUITS 1012310019
U3 IC. LINEAR MAR-4 MINI CIRCUITS 1010900005
U101 IC. DIGITAL, PLL MC145170D2 1013010035
U102 IC. DIGITAL, HEX INV. 74AC04SC 1013110030
U103 IC. LINEAR, XSTR ARRAY CA3096M 1013120035
U104 IC. LINEAR MAR-4 MINI CIRCUITS 1010900005
U105 IC. LINEAR LM340/7812 1003410022
U106 IC. LINEAR MAR-4 MINI CIRCUITS 1010900005
U107 IC. LINEAR LM340/7812 1003410022
U201 IC. DIGITAL, DDS AD9850BRS 1013000030
U202 IC. DIGITAL, CPLD CY7C37064 1013900006 I
U204 IC. DIGITAL MC74HC04AD 1013190033
U205 IC. DIGITAL MC74HC04AD 1013190033
U301 IC. DIGITAL, PLL MC145170D2 1013010035
U302 IC. LINEAR LM340/7812 1003410022
U303 IC. LINEAR, XSTR ARRAY CA3096M 1013120035
U304 IC. DIGITAL, HEX INV. 74AC04SC 1013110030
U305 IC. LINEAR UA78L05ACLP 1010150014
U306 IC. DIGITAL CD4047BE 1012190030
U307 IC. LINEAR MAR-4 MINI CIRCUITS 1010900005
U308 IC. LINEAR MAR-4 MINI CIRCUITS 1010900005
U401 SYNTHESIZER CPU W/SOFTWARE 8076060494
U402 IC. DIGITAL, HEX INV. 74AC04SC 1013110030
U403 I.C. DIGITAL MC74HC74AD 1013210034
U404 IC. DIGITAL, SUPERVISOR TL7705ACD 1013130031
U405 IC. LINEAR LT1129IT 1012840034
U406 IC. DIGITAL, HEX INV. 74AC04SC 1013110030
U408 IC. LINEAR LM340T5 0448600005
U409 IC. LINEAR MAR-3 MINI CIRCUITS 1012310019
X301 MIXER, BROADBAND SBL-1 1003300006
XU401 SOCKET, IC, 24PIN, .300W 1012570029
(none) GROMMET, CATERPILLAR 0500590001 H
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Panel 7 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
PC Assembly, Ref. Mod.
8076069092
C1 CAP. 6.8PF, 200V, NPO,+/- .5PF 1012906892
C2 CAP. 12PF, 200V NPO 5% 1012901203
C3 CAP. 0.01UF, 50V, X7R, 20% 0281730008
C4 CAP. 1UF, 35V TANT 0281660000
L1 INDUCTOR, MOLDED, 68UH, 5% 0651650003
R1 RESISTOR 100K, 5%, 1/8W CF 1010801040
U1 IC, DIGITAL, HEX INV. MC74AC04N 1013100018
PC ASSY, REFERENCE MODIFICATION
Panel 1 of 1
Panel 1 of 1
Ref
Symbol
Sunair
Part No.
Revision B
changes:
N/
A
Release of redesigned Synthesizer 8076060095
module using Direct Digital Synthesis
Revision C
changes:
C124 From CAP, 27 PF, NPO, 5 %, 50 V 1013902700
To CAP, 33 PF, NPO, 5 %, 50 V 1013903307
C129 From CAP, 82 PF, NPO, 5 %, 50 V 1013908201
To CAP, 47 PF, NPO, 5 %, 50 V 1013904702
C130 From CAP, 56 PF, NPO, 5 %, 50 V 1013905601
To CAP, 27 PF, NPO, 5 %, 50 V 1013902700
C180 From CAP, 47 PF, NPO, 5 %, 50 V 1013904702
To CAP, 56 PF, NPO, 5 %, 50 V 1013905601
C181 From CAP, 27 PF, NPO, 5 %, 50 V 1013902700
To CAP, 39 PF, NPO, 5 %, 50 V 1013903901
C183 From CAP, 18 PF, NPO, 5 %, 50 V 1013901801
To CAP, 33 PF, NPO, 5 %, 50 V 1013903307
C314 From CAP, 22 PF, NPO, 5 %, 50 V 1013902203
To CAP, 27 PF, NPO, 5 %, 50 V 1013902700
R112 From: RESISTOR, 1K, 5%, 1/8W 1013801024
To RESISTOR, 680, 5%, 1/8W 1013806816
R113 From RESISTOR, 1K, 5%, 1/8W 1013801024
To RESISTOR, 680, 5%, 1/8W 1013806816
R114 From RESISTOR, 1K, 5%, 1/8W 1013801024
To RESISTOR, 1.5K, 5%, 1/8W 1013801521
Revision D
changes:
C310 From CAP, 470 PF, NPO, 200V 1013904711
To CAP, 560 PF, NPO, 200V 1013905610
C314 From CAP, 27 PF, NPO, 5 %, 50 V 1013902700
To CAP, 33 PF, NPO, 5 %, 50 V 1013903307
C339 From CAP, 10PF, NPO, 5 %, 200 V 1013902700
To CAP, 33 PF, NPO, 5 %, 50 V 1013903307
R308 From RESISTOR, 1K, 5%, 1/8W 1013801822
To RESISTOR, 2.7K, 5%, 1/8W 1013802721
Revision E
changes:
C432 Add CAP, 12PF, NPO, 5%, 200V 1012901203
C433 Add CAP, 6.8PF, NPO, +/- 0.5PF, 200V 1012906892
L412 Add
INDUCTOR, MOLDED, 68UH, 5% 0651650003
R404 Add RESISTOR, 100K, 5%, 1/8W 1013801041
OR
(none) Add PC Assembly, Reference Modification 8076069092
(This assembly adds above listed fou
r
(4) components & circuitry as an
interim addition.
Revision F
changes:
(none) Add Add Humiseal® 1B31sealant to 1st and
2nd LO areas of top side of synthesize
r
PC Board. Components in above treated
areas require spot reapplication of
after component replacement.
Revision G
changes:
L306 From INDUCTOR, SMT, 1.0UH, 5% 1013902700
To INDUCTOR, MOLDED, 1.0UH, 5% 0648360008
Q305 Delete TRANSISTOR, N-CH FET, 2N7002 1013080033
Revision H
changes:
(none) Add Add Caterpillar Grommet 1/8" long to 0500590001
each end of the top of synthesizer
assembly metal backplane.
Revision I
changes:
U202 From IC. DIGITAL, CPLD CY7C372I-66JC 1012950034
To IC. DIGITAL, CPLD CY7C37064 1013900006
PC ASSEMBLY, SYNTHESIZER , 1A2A2
Revision Related Component Changes
Description
Notes
1. The above Revision-related component change information is provided to help end-users perform proper component replacement.
2. Unless otherwise directed by Sunair, all field-replaced components should be replaced with those specified for your specific Synthesizer Revision level.
3. The Synthesizer Assembly Revision Level is marked with an alphabetic character and is located along the top front edge of the PC Board in the center.
Figure 8.7 1A2A2 Synthesizer Assembly – DDS Version – Parts List (Sheet 2 of 2)
