RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-33
RT-9000C
Figure 8.12 1A2A4 Digital IF Assembly
Parts List (Sheet 1 of 3)
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
PC Assembly, Digital IF Board
8121080096 A
C1 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C2 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C3 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C4 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C5 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C6 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C7 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C8 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C9 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C10 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C11 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C12 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C13 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C14 CAP. 10UF, 16V, 10% 1016410000
C15 CAP. 0.001UF, 50V X7R, 10% 1016380003
C16 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C17 CAP. 0.001UF, 50V X7R, 10% 1016380003
C18 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C19 CAP. 0.001UF, 50V X7R, 10% 1016380003
C20 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C21 CAP. 0.001UF, 50V X7R, 10% 1016380003
C22 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C23 CAP. 18PF, NPO, 5%, 200V 1013901801
C24 CAP. 18PF, NPO, 5%, 200V 1013901801
C25 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C26 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C27 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C28 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C29 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C31 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C32 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C35 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C36 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C39 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C40 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C41 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C45 CAP. 100PF, NPO, 5%, 200V 1013901011
C46 CAP. 82PF, NPO, 5%, 200V 1013908201
C47 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C48 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C49 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C50 CAP. 82PF, NPO, 5%, 200V 1013908201
C51 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C52 CAP. 47PF, NPO, 5%, 200V 1013904702
C53 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C54 CAP. 82PF, NPO, 5%, 200V 1013908201
C55 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C56 CAP. 47PF, NPO, 5%, 200V 1013904702
C57 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C58 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C59 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C60 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C61 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C63 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C64 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C65 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C66 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C67 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C68 CAP. 10PF, NPO, 5%, 200V 1013901002
C69
CAP. 0.001UF, 50V X7R, 10%
1016380003
C70 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C71 CAP. 0.001UF, 50V X7R, 10% 1016380003
C72 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C73 CAP. 0.001UF, 50V X7R, 10% 1016380003
C74 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C75 CAP. 0.001UF, 50V X7R, 10% 1016380003
C76 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C77 CAP. 0.001UF, 50V X7R, 10% 1016380003
C78 CAP. 0.1UF, 16V, X7R, 10% 1016400004
PC ASSEMBLY, Digital IF Board Panel 1 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C79
CAP. 0.1UF, 16V, X7R, 10%
1016400004
C80 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C81 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C82 CAP. 10PF, NPO, 5%, 200V 1013901002
C83 CAP. 0.001UF, 50V X7R, 10% 1016380003
C84 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C85 CAP. 0.001UF, 50V X7R, 10% 1016380003
C86 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C87 CAP. 0.001UF, 50V X7R, 10% 1016380003
C88 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C89 CAP. 0.001UF, 50V X7R, 10% 1016380003
C90 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C91 CAP. 0.001UF, 50V X7R, 10% 1016380003
C92 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C93 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C94 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C95 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C96 CAP. 0.001UF, 50V X7R, 10% 1016380003
C97 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C98 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C99 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C100 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C101 CAP. 100PF, NPO, 5%, 200V 1013901011
C102 CAP. 180PF, NPO, 5%, 200V 1013901819
C103 CAP. 100PF, NPO, 5%, 200V 1013901011
C104 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C105 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C106 CAP. 0.001UF, 50V X7R, 10% 1016380003
C107 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C108 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C109 CAP. 1UF, 16V, 20% 1013050037
C110 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C111 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C112 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C113 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C116 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C117 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C118 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C125 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C126 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C127 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C129 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C130 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C131 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C132 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C133 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C134 CAP. 10UF, 16V, 10% 1016410000
C135 CAP. 10UF, 16V, 10% 1016410000
C136 CAP. 10UF, 16V, 10% 1016410000
C137 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C138
CAP. 0.1UF, 16V, X7R, 10%
1016400004
C139 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C140 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C141 CAP. 1UF, 16V, 20% 1013050037
C142 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C143 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C144 CAP. 10UF, 16V, 10% 1016410000
C145 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C146 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C147 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C148 CAP. 10UF, 16V, 10% 1016410000
C149 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C150 CAP. 10UF, 16V, 10% 1016410000
C151 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C152 CAP. 10UF, 16V, 10% 1016410000
C153 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C154 CAP. 10UF, 16V, 10% 1016410000
C155 CAP. 0.001UF, 50V X7R, 10% 1016380003
C156 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C157 CAP. 0.01UF, 16V, X7R, 10% 1016390009
PC ASSEMBLY, Digital IF Board Panel 2 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C158
CAP. 0.001UF, 50V X7R, 10%
1016380003
C159 CAP. 47UF, 10V, 10% 1016460007
C160 CAP. 47UF, 10V, 10% 1016460007
C161 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C162 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C163 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C164 CAP. 0.001UF, 50V X7R, 10% 1016380003
C165 CAP. 10UF, 16V, 10% 1016410000
C201 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C202 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C203 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C204 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C205 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C206 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C207 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C208 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C209 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C210 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C211 CAP. 10UF, 16V, 10% 1016410000
C212 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C213 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C214 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C215 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C216 CAP. 10UF, 16V, 10% 1016410000
C217 CAP. 1800PF, NPO, 5%, 200V 1013901827
C218 CAP. 5600PF, NPO, 5%, 200V 1013905628
C219 CAP. 390PF, NPO, 5%, 200V 1013903919
C220 CAP. 1800PF, NPO, 5%, 200V 1013901827
C221 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C222 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C223 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C224 CAP. 10UF, 16V, 10% 1016410000
C225 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C226 CAP. 2200PF, NPO, 5%, 200V 1013902220
C227 CAP. 0.001UF, 50V X7R, 10% 1016380003
C228 CAP. 0.47UF, 16V, 20% 1016790007
C229 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C230 CAP. 0.001UF, 50V X7R, 10% 1016380003
C231 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C232 CAP. 0.1UF, 16V, 20% 1016780001
C252
CAP. 0.01UF, 16V, X7R, 10%
1016390009
C301 CAP. 10UF, 16V, 10% 1016410000
C302 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C303 CAP. 10UF, 16V, 10% 1016410000
C304 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C305 CAP. 10UF, 16V, 10% 1016410000
C306 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C307 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C308 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C309 CAP. 10UF, 16V, 10% 1016410000
C310 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C311 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C312 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C313 CAP. 10UF, 16V, 10% 1016410000
C314 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C315 CAP. 10UF, 16V, 10% 1016410000
C316 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C317 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C318 CAP. 10UF, 16V, 10% 1016410000
C319 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C320 CAP. 10UF, 16V, 10% 1016410000
C321 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C322 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C323 CAP. 10UF, 16V, 10% 1016410000
C324 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C326 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C328 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C330 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C331 CAP. 10UF, 16V, 10% 1016410000
C332 CAP. 0.1UF, 16V, X7R, 10% 1016400004
PC ASSEMBLY, Digital IF Board Panel 3 of 10
Description
Sunair
Part No.
Notes/
Rev
Standard Digital IF Assembly 8121090091 1, 3
TADIL A / Link 11 Option 8109080090 2, 3
CANNOT be installed in the field.
3. These features and options are implemented via firmware residing
in memory device U403. This firmware is factory installed and
Notes
1. Implements all standard RT-9000C features.
2. Implements TADIL A / Link 11 operation per MIL-STD-188-203-1A.
Digital IF Assembly Variations
