RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-34
RT-9000C
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C334 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C336 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C337 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C338 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C340 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C342 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C343 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C344 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C345 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C346 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C347 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C348 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C349 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C350 CAP. 10UF, 16V, 10% 1016410000
C351 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C352 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C353 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C354 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C401 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C402 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C403 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C404 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C405 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C406 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C407 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C408 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C409 CAP. 10UF, 16V, 10% 1016410000
C410 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C411 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C412 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C413
CAP. 0.01UF, 16V, X7R, 10%
1016390009
C414 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C415 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C416 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C417 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C418 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C419 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C420 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C421 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C422 CAP. 47UF, 10V, 10% 1016460007
C423 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C424 CAP. 10PF, 50V, NPO, 5% 1016480008
C425 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C426 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C427 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C428 CAP. 33PF, NPO, 5%, 200V 1013903307
C429 CAP. 33PF, NPO, 5%, 200V 1013903307
C430 CAP. 10UF, 16V, 10% 1016410000
C431 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C432 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C433 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C434 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C435 CAP. 10UF, 16V, 10% 1016410000
C436 CAP. 10UF, 16V, 10% 1016410000
C437 CAP. 47UF, 10V, 10% 1016460007
C438 CAP. 47UF, 10V, 10% 1016460007
C439 CAP. 47UF, 10V, 10% 1016460007
C440 CAP. 10UF, 16V, 10% 1016410000
C441 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C442 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C443 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C444 CAP. 47UF, 10V, 10% 1016460007
C445 CAP. 47UF, 10V, 10% 1016460007
C446 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C447 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C448 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C449 CAP. 0.01UF, 16V, X7R, 10% 1016390009
CR1 DIODE, PIN HSMP-3820 1013170032
CR2 DIODE, PIN HSMP-3820 1013170032
CR3 DIODE, PIN HSMP-3820 1013170032
PC ASSEMBLY, Digital IF Board Panel 4 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
CR4 DIODE, PIN HSMP-3820 1013170032
CR5 DIODE, PIN HSMP-3820 1013170032
CR6 DIODE, PIN HSMP-3820 1013170032
CR7 DIODE, SIGNAL, SIL MMBD914 1013150031
CR9 DIODE, PIN, HSMP-3810 1015830005
CR10 DIODE, PIN, HSMP-3810 1015830005
CR11 DIODE, SCHOTTKY BAS70 1015910009
CR12 DIODE, SCHOTTKY BAS70 1015910009
CR13 DIODE, SCHOTTKY BAS70 1015910009
CR14 DIODE, SCHOTTKY BAS70 1015910009
CR15 DIODE, SCHOTTKY BAS70 1015910009
CR16 DIODE, SCHOTTKY BAS70 1015910009
CR17 DIODE, PIN HSMP-3820 1013170032
CR18 DIODE, LED, RED 550-2405 1008480029
CR19 DIODE, SIGNAL, SIL MMBD914 1013150031
CR20 DIODE, SCHOTTKY BAS70 1015910009
CR21 DIODE, SIGNAL, SIL MMBD914 1013150031
CR22 DIODE, SIGNAL, SIL MMBD914 1013150031
CR23 DIODE, PIN, HSMP-3810 1015830005
CR24 DIODE, PIN, HSMP-3810 1015830005
CR25
DIODE, SCHOTTKY BAS70
1015910009
CR26 DIODE, SCHOTTKY BAS70 1015910009
CR27 DIODE, SCHOTTKY BAS70 1015910009
CR28 DIODE, PIN, HSMP-3810 1015830005
CR29 DIODE, PIN, HSMP-3810 1015830005
CR30 DIODE, SCHOTTKY BAS70 1015910009
CR301 DIODE, SCHOTTKY HSMS-2820 1013160037
CR302 DIODE, SCHOTTKY HSMS-2820 1013160037
CR303 DIODE, SCHOTTKY HSMS-2820 1013160037
CR401 DIODE, SCHOTTKY, MBRS-320 1015710000
FB1 FERRITE BEAD, EXCML32A680U 1015880002
FB2 FERRITE BEAD, EXCML32A680U 1015880002
FB3 FERRITE BEAD, EXCML32A680U 1015880002
FB4 FERRITE BEAD 2773021447 1016350007
FB5 FERRITE BEAD 2773021447 1016350007
FB6 FERRITE BEAD, EXCML32A680U 1015880002
FB7 FERRITE BEAD, EXCML32A680U 1015880002
FB8 FERRITE BEAD, EXCML32A680U 1015880002
FB9 COMMON MODE CHOKE 2744051447 1016360002
FB10 FERRITE BEAD 2773021447 1016350007
FB11 FERRITE BEAD, EXCML32A680U 1015880002
FB12 FERRITE BEAD, EXCML32A680U 1015880002
FB13 FERRITE BEAD, EXCML32A680U 1015880002
FB14 FERRITE BEAD, EXCML32A680U 1015880002
FB15 FERRITE BEAD, EXCML32A680U 1015880002
FB16 FERRITE BEAD 2512066017YO 1016680007
FB18 FERRITE BEAD, EXCML32A680U 1015880002
FB19 FERRITE BEAD, EXCML32A680U 1015880002
FB20 FERRITE BEAD, EXCML32A680U 1015880002
FB21 FERRITE BEAD 2773021447 1016350007
FB22 FERRITE BEAD 2773021447 1016350007
FB23 FERRITE BEAD 2773021447 1016350007
FB24 FERRITE BEAD 2773021447 1016350007
FB25 FERRITE BEAD 2773021447 1016350007
FB26 FERRITE BEAD, EXCML32A680U 1015880002
FB27 FERRITE BEAD, EXCML32A680U 1015880002
FB28 FERRITE BEAD, EXCML32A680U 1015880002
FB29 FERRITE BEAD, EXCML32A680U 1015880002
FB30 FERRITE BEAD, EXCML32A680U 1015880002
FB201 FERRITE BEAD, EXCML32A680U 1015880002
FB202 FERRITE BEAD 2512066017YO 1016680007
FB203 FERRITE BEAD 2512066017YO 1016680007
FB301 FERRITE BEAD, EXCML32A680U 1015880002
FB302 FERRITE BEAD, EXCML32A680U 1015880002
FB303 FERRITE BEAD, EXCML32A680U 1015880002
FB304 FERRITE BEAD, EXCML32A680U 1015880002
FB305 FERRITE BEAD, EXCML32A680U 1015880002
FB401 FERRITE BEAD, EXCML32A680U 1015880002
FB402 FERRITE BEAD, EXCML32A680U 1015880002
FL1 FILTER, 48.305MHZ, FN-3538 1016710003
PC ASSEMBLY, Digital IF Board Panel 5 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
FL2 FILTER USB OPERATION 1015540007
FL3 FILTER LSB OPERATION 1015550002
FL4 FILTER ISB/AM OPERATION 1015560008
J1 CONNECTOR HEADER 34PIN MALE 1016840004
J2 CONNECTOR HEADER 12PIN MALE 1016890001
J3 CONNECTOR HEADER 10PIN MALE 1016830009
J401 HEADER, PC, 14 PIN DUAL 1008180009
J402 CONNECTOR HEADER 10 PIN MALE 1016450001
J403 CONNECTOR, HEADER, 10 PIN MALE 1010800027
L1 INDUCTOR, SMT, 390UH, 5% 1013703910
L3
INDUCTOR, SMT, 2.7UH, 5%
1013702794
L4 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L5 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L6 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L7 INDUCTOR, SMT, 220UH, 5% 1013702212
L8 INDUCTOR, SMT, 220UH, 5% 1013702212
L9 INDUCTOR, SMT, 220UH, 5% 1013702212
L10 INDUCTOR, SMT, 220UH, 5% 1013702212
L11 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L12 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L13 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L17 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L20 INDUCTOR, SMT, .18UH, 5% 1013701887
L21 INDUCTOR, SMT, .18UH, 5% 1013701887
L22 INDUCTOR, SMT, 2.7UH, 5% 1013702794
L23 INDUCTOR, SMT, 390UH, 5% 1013703910
L24 INDUCTOR, SMT, 390UH, 5% 1013703910
L202 INDUCTOR, SMT, 12UH, 5% 1013701208
L203 INDUCTOR, SMT, 12UH, 5% 1013701208
P3 CONNECTOR, RF, RIGHT ANGLE 1010730002
P4 CONNECTOR, RF, RIGHT ANGLE 1010730002
P5 CONNECTOR, RF, RIGHT ANGLE 1010730002
P6 HEADER, PIN STRIP, 3 PIN 1011230020
P201 HEADER, PIN STRIP, 3 PIN 1011230020
Q3 TRANSISTOR, P-CH, FET 25P03L 1016810008
Q4 TRANSISTOR, P-CH, FET 25P03L 1016810008
Q5 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q6 TRANSISTOR, NPN MMBT4124 1013090039
Q7 TRANSISTOR, NPN SI. MJD200 1016640005
Q8 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q9 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q10 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q11 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q12 TRANSISTOR, NPN MMBT4124 1013090039
Q13 TRANSISTOR, NPN MMBT4124 1013090039
Q14 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q15 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q16 TRANSISTOR, N-CH, FET 2N7002 1013080033
R1 RESISTOR 820, 5%, 1/8W 1013808215
R2 RESISTOR 2.00K, 1% 1/8W 1014680000
R3 RESISTOR 820, 5%, 1/8W 1013808215
R4 RESISTOR 820, 5%, 1/8W 1013808215
R5 RESISTOR 2.00K, 1% 1/8W 1014680000
R6 RESISTOR 820, 5%, 1/8W 1013808215
R7 RESISTOR 27, 5%, 1/8W 1013802705
R8 RESISTOR 820, 5%, 1/8W 1013808215
R9 RESISTOR 820, 5%, 1/8W 1013808215
R10 RESISTOR 820, 5%, 1/8W 1013808215
R11 RESISTOR 470, 5%, 1/8W 1013804716
R12 RESISTOR 470, 5%, 1/8W 1013804716
R13 RESISTOR 470, 5%, 1/8W 1013804716
R14 RESISTOR 120, 5%, 1/8W 1013801211
R15 RESISTOR 27, 5%, 1/8W 1013802705
R17 RESISTOR 470, 5%, 1/8W 1013804716
R18 RESISTOR 470, 5%, 1/8W 1013804716
R19 RESISTOR 470, 5%, 1/8W 1013804716
R20 RESISTOR 100, 5%, 1/8W 1013801016
R21 RESISTOR 100, 5%, 1/8W 1013801016
R22 RESISTOR 100, 5%, 1/8W 1013801016
R24 RESISTOR 100, 5%, 1/8W 1013801016
PC ASSEMBLY, Digital IF Board Panel 6 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R25 RESISTOR 100K, 5%, 1/8W 1013801041
R26 RESISTOR 100, 5%, 1/8W 1013801016
R27 RESISTOR 100K, 5%, 1/8W 1013801041
R28 RESISTOR 100, 5%, 1/8W 1013801016
R29 RESISTOR 100K, 5%, 1/8W 1013801041
R30 RESISTOR 100K, 5%, 1/8W 1013801041
R31 RESISTOR 47K, 5%, 1/8W 1013804732
R32 RESISTOR 47K, 5%, 1/8W 1013804732
R33 RESISTOR 100K, 5%, 1/8W 1013801041
R34 RESISTOR 47K, 5%, 1/8W 1013804732
R35
RESISTOR 47K, 5%, 1/8W
1013804732
R36 RESISTOR 100K, 5%, 1/8W 1013801041
R37 RESISTOR 100K, 5%, 1/8W 1013801041
R38 RESISTOR, 274, 1%, 1/8W 1016010001
R39 RESISTOR, 274, 1%, 1/8W 1016010001
R40 RESISTOR 100, 5%, 1/8W 1013801016
R41 RESISTOR 22, 5%, 1/8W 1013802209
R45 RESISTOR 27, 5%, 1/8W 1013802705
R46 RESISTOR 100, 5%, 1/8W 1013801016
R47 RESISTOR 27, 5%, 1/8W 1013802705
R51 RESISTOR 27, 5%, 1/8W 1013802705
R55 RESISTOR 2.7K, 5%, 1/8W 1013802721
R56 RESISTOR 2.2K, 5%, 1/8W 1013802225
R57 RESISTOR 1.8K, 5%, 1/8W 1013801822
R58 RESISTOR 8.2K, 5%, 1/8W 1013808223
R59 RESISTOR 6.8K, 5%, 1/8W 1013806824
R60 RESISTOR, 10K, 1% 1/10W 1016420005
R61 RESISTOR 22K, 5%, 1/8W 1013802233
R63 RESISTOR 1.5K, 5%, 1/8W 1013801521
R64 RESISTOR 100, 5%, 1/8W 1013801016
R65 RESISTOR 560K, 5%, 1/8W 1013805640
R67 RESISTOR 1.5K, 5%, 1/8W 1013801521
R68 RESISTOR 100K, 5%, 1/8W 1013801041
R69 RESISTOR, 1K, 1%, 1/10W 1016850000
R70 POT. 100K, 10%, 3/4W, 15 TURNS 0338490051
R71 RESISTOR, 10K, 1% 1/10W 1016420005
R72 RESISTOR 100K, 5%, 1/8W 1013801041
R73 RESISTOR, 10K, 1% 1/10W 1016420005
R74 RESISTOR 47K, 5%, 1/8W 1013804732
R75 RESISTOR 8.2K, 5%, 1/8W 1013808223
R76 RESISTOR 5.6K, 5%, 1/8W 1013805623
R77 POT. 2K, 10%, 3/4W, 15 TURNS 0338490060
R78 POT. 2K, 10%, 3/4W, 15 TURNS 0338490060
R80 RESISTOR, 1K, 1%, 1/10W 1016850000
R81 RESISTOR 22, 5%, 1/8W 1013802209
R82 RESISTOR 10, 5%, 1/8W 1013801008
R83 RESISTOR 1.8K, 5%, 1/8W 1013801822
R84 RESISTOR 100K, 5%, 1/8W 1013801041
R85 RESISTOR 4.7K, 5%, 1/8W 1013804724
R86 RESISTOR 4.7K, 5%, 1/8W 1013804724
R87 RESISTOR, 10K, 1% 1/10W 1016420005
R88 RESISTOR 120K, 5%, 1/8W 1013801245
R89 RESISTOR, 10K, 1% 1/10W 1016420005
R90 RESISTOR 100K, 5%, 1/8W 1013801041
R91 RESISTOR, 10K, 1% 1/10W 1016420005
R92 RESISTOR, 10K, 1% 1/10W 1016420005
R93 RESISTOR 1.2K, 5%, 1/8W 1013801229
R94 RESISTOR 12K, 5%, 1/8W 1013801237
R95 RESISTOR 390, 5%, 1/8W 1013803914
R96 RESISTOR, 10K, 1% 1/10W 1016420005
R97 RESISTOR, 1K, 1%, 1/10W 1016850000
R101 RESISTOR 26.1K, 1% 1/8W 1014790000
R102 RESISTOR 8.66K, 1% 1/8W 1014730007
R103 RESISTOR 1.00K, 1% 1/8W 1014670004
R104 RESISTOR, 68.1K, 1%, 1/10W 1017080003
R105 RESISTOR, 10K, 1% 1/10W 1016420005
R106 RESISTOR 330, 5%, 1/8W 1013803311
R107 RESISTOR 4.7K, 5%, 1/8W 1013804724
R108 RESISTOR 4.7K, 5%, 1/8W 1013804724
R109 RESISTOR, 1K, 1%, 1/10W 1016850000
PC ASSEMBLY, Digital IF Board Panel 7 of 10
Figure 8.12 1A2A4 Digital IF Assembly – Parts List (Sheet 2 of 3)
To Next Page
Loading...
