RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-35
RT-9000C
Figure 8.12 1A2A4 Digital IF Assembly
Parts List (Sheet 3 of 3)
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R429 RESISTOR, 10K, 1% 1/10W 1016420005
R430 RESISTOR 0.0, 0%, 1/4W 1011600021
R431 RESISTOR, 1K, 1%, 1/10W 1016850000
R432 RESISTOR, 1K, 1%, 1/10W 1016850000
R433 RESISTOR, 1K, 1%, 1/10W 1016850000
R434 RESISTOR, 10K, 1% 1/10W 1016420005
R435 RESISTOR, 1K, 1%, 1/10W 1016850000
R436 RESISTOR, 1K, 1%, 1/10W 1016850000
R437 RESISTOR, 10K, 1% 1/10W 1016420005
R438 RESISTOR, 10K, 1% 1/10W 1016420005
R439
RESISTOR, 10K, 1% 1/10W
1016420005
R440 RESISTOR, 10K, 1% 1/10W 1016420005
R441 RESISTOR, 10K, 1% 1/10W 1016420005
R442 RESISTOR, 10K, 1% 1/10W 1016420005
R443 RESISTOR 4.7K, 5%, 1/8W 1013804724
R444 RESISTOR, 10K, 1% 1/10W 1016420005
R445 RESISTOR, 1K, 1%, 1/10W 1016850000
R446 RESISTOR, 10K, 1% 1/10W 1016420005
R447 RESISTOR, 10K, 1% 1/10W 1016420005
R448 RESISTOR, 10K, 1% 1/10W 1016420005
T1 TRANSFORMER, RF 1:1 ADT1-6T 1016670001
T2 TRANSFORMER, RF, 4:1 TCM4-1W 1015780008
T3 TRANSFORMER, RF, 4:1 TCM4-1W 1015780008
T4 TRANSFORMER, RF, 2.5:1 T2.5-6 1016690002
T6 TRANSFORMER, RF, 36:1 T36-1 1015860001
T7 TRANSFORMER, RF, 36:1 T36-1 1015860001
T8 TRANSFORMER, RF, 36:1 T36-1 1015860001
T9 TRANSFORMER, RF, 36:1 T36-1 1015860001
T11 TRANSFORMER, RF, 16:1 T16-6T 1015820000
T12 TRANSFORMER, RF, 16:1 T16-6T 1015820000
T201 TRANSFORMER, RF 4:1 T4-6T 1015650007
T202 COMMON MODE CHOKE, PE-68624 1015660002
T203 TRANSFORMER, RF 1:1 ADT1-6T 1016670001
T301 COMMON MODE CHOKE, PE-68624 1015660002
T302 COMMON MODE CHOKE, PE-68624 1015660002
T303 COMMON MODE CHOKE 23Z104SM 1016430001
T305 COMMON MODE CHOKE 23Z104SM 1016430001
T306 COMMON MODE CHOKE 23Z104SM 1016430001
T307 COMMON MODE CHOKE 23Z104SM 1016430001
T308 COMMON MODE CHOKE 23Z104SM 1016430001
T309 COMMON MODE CHOKE 23Z104SM 1016430001
T310 COMMON MODE CHOKE 23Z104SM 1016430001
T401 COMMON MODE CHOKE 23Z104SM 1016430001
TP1 TEST POINT, RED 1011130033
TP201 TEST POINT, RED 1011130033
U1 IC. LINEAR, VGA AD8331ARQ 1015590004
U2 IC. LINEAR, RF3378 1016600003
U3 IC. LINEAR PI5A4624 1015850006
U4 IC. LINEAR PI5A4624 1015850006
U5 IC. LINEAR PI5A4624 1015850006
U6 IC. LINEAR PI5A4624 1015850006
U7 IC. LINEAR, VGA AD8331ARQ 1015590004
U8 IC. LINEAR, VGA AD8331ARQ 1015590004
U9 IC LINEAR MC34074 1014100003
U10 IC. LINEAR, RF3378 1016600003
U11 IC. DIGITAL, 4584 1016060009
U12 IC. LINEAR, RF3378 1016600003
U13 IC. LINEAR, RF3378 1016600003
U14 IC. LINEAR, RF3378 1016600003
U15 IC LINEAR MC34072 1014090008
U17 IC. LINEAR, LTC1565-31CS8 1015890008
U18 IC. LINEAR, LTC1565-31CS8 1015890008
U19 IC LINEAR MC34074 1014100003
U20 IC LINEAR MC34074 1014100003
U21 IC. LINEAR LM2903D 1015940005
U201 IC. DIGITAL, DDS AD9857AST 1015570003
U202 IC. DIGITAL, ADF4001 1016660006
U203 OSCILLATOR, VCXO 5.005MHZ 1015950001
U204 IC. DIGITAL 74LVC374A 1015970001
U205 IC. DIGITAL 74LVC374A 1015970001
PC ASSEMBLY, Digital IF Board Panel 9 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
U206 IC. DIGITAL 74LVC374A 1015970001
U207 IC. DIGITAL, PS2801-4 1016030002
U208 IC. LINEAR, LT1713CMS8 1015770002
U209 IC. DIGITAL, HEX INV. 74AC04 1013110030
U301 IC. DIGITAL, A/D LTC1402CGN 1015690009
U302 IC. DIGITAL, A/D LTC1402CGN 1015690009
U303 IC. DIGITAL, A/D LTC1401CS8 1015600000
U304 IC. DIGITAL, A/D LTC1401CS8 1015600000
U305 IC. DIGITAL, A/D LTC1401CS8 1015600000
U306 IC. DIGITAL, D/A LTC2601CDD 1015610005
U307
IC. DIGITAL, D/A LTC2601CDD
1015610005
U308 IC. DIGITAL, D/A LTC2621CDD 1015620001
U309 IC. DIGITAL, D/A LTC2621CDD 1015620001
U310 IC. DIGITAL, D/A LTC2621CDD 1015620001
U311 IC. LINEAR, REF3212 1016760001
U312 IC. LINEAR, REF3230 1016770006
U313 IC. DIGITAL, D/A LTC2621CDD 1015620001
U314 IC. DIGITAL, A/D LTC1598LCG 1015740006
U315 IC. DIGITAL, D/A LTC2601CDD 1015610005
U316 IC. LINEAR, REF3230 1016770006
U317 IC. DIGITAL, SN65LVDS047 1016750005
U318 IC. DIGITAL, SN65LVDT2 1016740000
U401 IC. DIGITAL, DSP ADSP-21262 1015520006
U402 IC. DIGITAL, 74LVC373A 1015960006
U403 IC. DIGITAL, AT25F2048N 1015700004
U404 IC. DIGITAL, 74LVC157A 1016470002
U405 IC. DIGITAL, 74LVC138A 1015990002
U406 IC. DIGITAL 74LVC32A 1016000006
U407 IC. DIGITAL, TL7733BCD 1016370008
U408 IC. DIGITAL EPM3064 1017070008
U409 IC. DIGITAL, PS2801-4 1016030002
U410 IC. DIGITAL, 74LVC244A 1015980007
U411 IC. DIGITAL 74LVC374A 1015970001
U412 IC. DIGITAL, PS2801-4 1016030002
U413 IC LINEAR, VOLT REG,LT1521-3.3 1015330002
U414 IC. LINEAR LT1963AEQ 1015750001
U415 IC. DIGITAL, 74LVC244A 1015980007
U416 IC. DIGITAL, PS2801-4 1016030002
U417 IC. DIGITAL, PS2801-1 1016020007
U418 IC. DIGITAL, PS2801-4 1016030002
U419 IC. DIGITAL, SN65LVDS047 1016750005
U420 IC. DIGITAL, SN65LVDT2 1016740000
U421 IC. DIGITAL, PS2801-1 1016020007
X1 MIXER, ADE-2 1016700008
X401 CRYSTAL, 12.500MHZ 1015760007
SHIELD 6.5X3.25X.5 1017190003
SHIELD 2.25X1.5X.5 1017200009
MOUNTING PLATE, DIGITAL IF 8121081602
PC ASSEMBLY, Digital IF Board Panel 10 of 10
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R110 RESISTOR 560, 5%, 1/8W 1013805615
R111 RESISTOR 2.7K, 5%, 1/8W 1013802721
R112 RESISTOR 12K, 5%, 1/8W 1013801237
R113 RESISTOR 100K, 5%, 1/8W 1013801041
R114 RESISTOR 100K, 5%, 1/8W 1013801041
R115 RESISTOR, 10K, 1% 1/10W 1016420005
R116 RESISTOR, 1K, 1%, 1/10W 1016850000
R117 RESISTOR 5.76K, 1% 1/8W 1014710006
R118 RESISTOR 26.1K, 1% 1/8W 1014790000
R119 RESISTOR 2.2K, 5%, 1/8W 1013802225
R121
RESISTOR, 68.1K, 1%, 1/10W
1017080003
R201 RESISTOR 4.7K, 5%, 1/8W 1013804724
R202 RESISTOR 5.6K, 5%, 1/8W 1013805623
R203 RESISTOR 51.1K, 1% 1/8W 1014810001
R204 RESISTOR 49.9 1% 1/8W 1014640008
R205 RESISTOR 2.00K, 1% 1/8W 1014680000
R206 RESISTOR 1.00K, 1% 1/8W 1014670004
R207 RESISTOR 49.9 1% 1/8W 1014640008
R208 RESISTOR 49.9 1% 1/8W 1014640008
R209 RESISTOR, 10K, 1% 1/10W 1016420005
R210 RESISTOR 49.9 1% 1/8W 1014640008
R211 RESISTOR, 10K, 1% 1/10W 1016420005
R212 RESISTOR, 10K, 1% 1/10W 1016420005
R213 RESISTOR, 10K, 1% 1/10W 1016420005
R214 RESISTOR, 1K, 1%, 1/10W 1016850000
R215 RESISTOR, 1K, 1%, 1/10W 1016850000
R216 RESISTOR, 1K, 1%, 1/10W 1016850000
R217 RESISTOR, 1K, 1%, 1/10W 1016850000
R218 RESISTOR 49.9 1% 1/8W 1014640008
R219 RESISTOR 470, 5%, 1/8W 1013804716
R301 RESISTOR 3.74K, 1%, 1/8W 1014690005
R302 RESISTOR 3.74K, 1%, 1/8W 1014690005
R303 RESISTOR, 30.1K, 1% 1/10W 1016860005
R304 RESISTOR, 30.1K, 1% 1/10W 1016860005
R305 RESISTOR, 30.1K, 1% 1/10W 1016860005
R306 RESISTOR, 10K, 1% 1/10W 1016420005
R307 RESISTOR, 30.1K, 1% 1/10W 1016860005
R308 RESISTOR, 10K, 1% 1/10W 1016420005
R309 RESISTOR 100, 5%, 1/8W 1013801016
R310 RESISTOR 100, 5%, 1/8W 1013801016
R311 RESISTOR, 10K, 1% 1/10W 1016420005
R312 RESISTOR 100, 5%, 1/8W 1013801016
R401 RESISTOR, 10K, 1% 1/10W 1016420005
R402 RESISTOR, 10K, 1% 1/10W 1016420005
R403 RESISTOR, 10K, 1% 1/10W 1016420005
R404 RESISTOR 1M, 5%, 1/8W 1013801059
R405 RESISTOR 4.7K, 5%, 1/8W 1013804724
R406 RESISTOR, 10K, 1% 1/10W 1016420005
R407 RESISTOR, 1K, 1%, 1/10W 1016850000
R408 RESISTOR, 10K, 1% 1/10W 1016420005
R409 RESISTOR, 10K, 1% 1/10W 1016420005
R410 RESISTOR, 10K, 1% 1/10W 1016420005
R411 RESISTOR, 10K, 1% 1/10W 1016420005
R412 RESISTOR, 10K, 1% 1/10W 1016420005
R413 RESISTOR, 10K, 1% 1/10W 1016420005
R414 RESISTOR 2.00K, 1% 1/8W 1014680000
R415 RESISTOR 10, 5%, 1/8W 1013801008
R416 RESISTOR, 10K, 1% 1/10W 1016420005
R417 RESISTOR, 10K, 1% 1/10W 1016420005
R418 RESISTOR, 10K, 1% 1/10W 1016420005
R419 RESISTOR, 10K, 1% 1/10W 1016420005
R420 RESISTOR, 10K, 1% 1/10W 1016420005
R421 RESISTOR, 10K, 1% 1/10W 1016420005
R422 RESISTOR, 10K, 1% 1/10W 1016420005
R423 RESISTOR, 10K, 1% 1/10W 1016420005
R424 RESISTOR, 10K, 1% 1/10W 1016420005
R425 RESISTOR, 10K, 1% 1/10W 1016420005
R426 RESISTOR, 10K, 1% 1/10W 1016420005
R427 RESISTOR, 10K, 1% 1/10W 1016420005
R428 RESISTOR, 10K, 1% 1/10W 1016420005
PC ASSEMBLY, Digital IF Board Panel 8 of 10
