RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-47
RT-9000C
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
PC Assembly, Digital Audio Board
8121090091 A
C1 CAP. 1800PF, 200V, NPO,2% 1017130001
C2 CAP. 4700PF, 200V, NPO, 2% 1017140006
C3 CAP. 8200PF, 200V, NPO, 2% 1017150001
C4 CAP. 1800PF, 200V, NPO,2% 1017130001
C5 CAP. 4700PF, 200V, NPO, 2% 1017140006
C6 CAP. 8200PF, 200V, NPO, 2% 1017150001
C7 CAP. 1800PF, 200V, NPO,2% 1017130001
C8 CAP. 4700PF, 200V, NPO, 2% 1017140006
C9 CAP. 8200PF, 200V, NPO, 2% 1017150001
C10 CAP. 1UF, 16V, 20% 1013050037
C11 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C12 CAP. 1UF, 16V, 20% 1013050037
C13 CAP. 1UF, 16V, 20% 1013050037
C14 CAP. 10UF, 16V, 20% 1013060032
C15 CAP. 47UF, 10V, 10% 1016460007
C16 CAP. 1UF, 16V, 20% 1013050037
C17 CAP. 1UF, 16V, 20% 1013050037
C18 CAP. 1UF, 16V, 20% 1013050037
C19 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C20 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C21 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C22 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C23 CAP. 10UF, 16V, 20% 1013060032
C24 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C25 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C26 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C27 CAP. 10UF, 16V, 20% 1013060032
C28 CAP. 10UF, 16V, 20% 1013060032
C29 CAP. 10UF, 16V, 20% 1013060032
C30 CAP. 10UF, 16V, 20% 1013060032
C31 CAP. 10UF, 16V, 20% 1013060032
C32 CAP. 10UF, 35V, 10% 1016540001
C33 CAP. 10UF, 35V, 10% 1016540001
C34 CAP. .1UF, 50V, X7R, 20% 1013040031
C35 CAP. 470UF, 50V 0280890001
C36 CAP. 10UF, 35V, 10% 1016540001
C37 CAP. 0.47UF, 50V, X7R, 20% 0283377771
C38 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C39 CAP. 1800PF, 200V, NPO,2% 1017130001
C40 CAP. 4700PF, 200V, NPO, 2% 1017140006
C41 CAP. 8200PF, 200V, NPO, 2% 1017150001
C42 CAP. 1UF, 16V, 20% 1013050037
C43 CAP. 1800PF, 200V, NPO,2% 1017130001
C44 CAP. 4700PF, 200V, NPO, 2% 1017140006
C45 CAP. 8200PF, 200V, NPO, 2% 1017150001
C46 CAP. 1UF, 16V, 20% 1013050037
C47 CAP. 1800PF, 200V, NPO,2% 1017130001
C48 CAP. 4700PF, 200V, NPO, 2% 1017140006
C49 CAP. 8200PF, 200V, NPO, 2% 1017150001
C50 CAP. 1UF, 16V, 20% 1013050037
C51 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C52 CAP. 10UF, 35V, 10% 1016540001
C53 CAP. 10UF, 35V, 10% 1016540001
C54 CAP. 10UF, 35V, 10% 1016540001
C55 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C56 CAP. 10UF, 35V, 10% 1016540001
C57 CAP. 10UF, 35V, 10% 1016540001
C58 CAP. .1UF, 50V, X7R, 20% 1013040031
C59 CAP. 10UF, 16V, 20% 1013060032
C60
CAP. 0.1UF, 16V, X7R, 10%
1016400004
C61 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C62 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C63 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C64 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C65 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C66 CAP. 10UF, 16V, 20% 1013060032
C67 CAP. 10UF, 16V, 20% 1013060032
C68 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C69 CAP. 1UF, 16V, 20% 1013050037
PC ASSEMBLY, Digital Audio Board Panel 1 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C70
CAP. 10UF, 16V, 20%
1013060032
C71 CAP. 1UF, 16V, 20% 1013050037
C72 CAP. 1UF, 16V, 20% 1013050037
C73 CAP. 10UF, 16V, 20% 1013060032
C74 CAP. 10UF, 16V, 20% 1013060032
C75 CAP. .1UF, 50V, X7R, 20% 1013040031
C76 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C77 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C78 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C79 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C80 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C81 CAP. 1500PF, 200V, NPO, 2% 1017120005
C82 CAP. 1500PF, 200V, NPO, 2% 1017120005
C83 CAP. 330PF, 200V NPO, 2% 1017110000
C84 CAP. 1500PF, 200V, NPO, 2% 1017120005
C85 CAP. 1500PF, 200V, NPO, 2% 1017120005
C86 CAP. 330PF, 200V NPO, 2% 1017110000
C87 CAP. 1500PF, 200V, NPO, 2% 1017120005
C88 CAP. 1500PF, 200V, NPO, 2% 1017120005
C89 CAP. 330PF, 200V NPO, 2% 1017110000
C90 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C91 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C92 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C93 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C94 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C95 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C96 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C97 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C98 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C99 CAP. 1500PF, 200V, NPO, 2% 1017120005
C100 CAP. 1500PF, 200V, NPO, 2% 1017120005
C101 CAP. 330PF, 200V NPO, 2% 1017110000
C102 CAP. 1500PF, 200V, NPO, 2% 1017120005
C103 CAP. 1500PF, 200V, NPO, 2% 1017120005
C104 CAP. 330PF, 200V NPO, 2% 1017110000
C105 CAP. 1500PF, 200V, NPO, 2% 1017120005
C106 CAP. 1500PF, 200V, NPO, 2% 1017120005
C107 CAP. 330PF, 200V NPO, 2% 1017110000
C108 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C109 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C110 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C111 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C112 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C113 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C114 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C115 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C116 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C117 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C118 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C119 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C120
CAP. .1UF, 50V, X7R, 20%
1013040031
C121 CAP. 0.47UF, 16V, X7R, 20% 1015870007
C122 CAP. .1UF, 50V, X7R, 20% 1013040031
C123 CAP. 1UF, 16V, 20% 1013050037
C124 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C125 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C126 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C127 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C128 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C129 CAP. 10UF, 16V, 20% 1013060032
C130 CAP. 10UF, 16V, 20% 1013060032
C131 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C132 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C133 CAP. 0.01UF, 16V, X7R, 10% 1016390009
C134 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C135 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C136 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C137 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C138 CAP. 0.1UF, 16V, X7R, 10% 1016400004
C139 CAP. 0.1UF, 16V, X7R, 10% 1016400004
PC ASSEMBLY, Digital Audio Board Panel 2 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
C140
CAP. 0.1UF, 16V, X7R, 10%
1016400004
CR1 DIODE, SIGNAL, SIL MMBD914 1013150031
CR2 DIODE, SIGNAL, SIL MMBD914 1013150031
CR3 DIODE, SIGNAL, SIL MMBD914 1013150031
CR4 DIODE, SIGNAL, SIL MMBD914 1013150031
CR5 DIODE, SIGNAL, SIL MMBD914 1013150031
CR6 DIODE, SIGNAL, SIL MMBD914 1013150031
CR7 DIODE, SIGNAL, SIL MMBD914 1013150031
CR8 DIODE, SIGNAL, SIL MMBD914 1013150031
CR9 DIODE, SIGNAL, SIL MMBD914 1013150031
CR10 DIODE, SIGNAL, SIL MMBD914 1013150031
CR11 DIODE, SIGNAL, SIL MMBD914 1013150031
CR12 DIODE, SIGNAL, SIL MMBD914 1013150031
CR13 DIODE, LED, RED 550-2405 1008480029
CR14 DIODE, SIGNAL, SIL MMBD914 1013150031
CR15 DIODE, SIGNAL, SIL MMBD914 1013150031
CR16 DIODE, SIGNAL, SIL MMBD914 1013150031
CR17 DIODE, SIGNAL, SIL MMBD914 1013150031
CR18 DIODE, SIGNAL, SIL MMBD914 1013150031
CR19 DIODE, SIGNAL, SIL MMBD914 1013150031
FB1 FERRITE BEAD 2773021447 1016350007
FB2 FERRITE BEAD 2773021447 1016350007
FB3 FERRITE BEAD 2773021447 1016350007
J1 CONNECTOR HEADER 34PIN MALE 1016840004
K1 RELAY, DPDT, 28V, .3A 1013120001
K2 RELAY, DPDT, 12V, PC MOUNT 1014040001
K3 RELAY, DPDT, 12V, PC MOUNT 1014040001
K4 RELAY, DPDT, 12V, PC MOUNT 1014040001
P3 HEADER, PIN STRIP, 3 PIN 1011230020
P4 HEADER, PIN STRIP, 3 PIN 1011230020
P5 HEADER, PIN STRIP, 3 PIN 1011230020
P6 HEADER, PIN STRIP, 3 PIN 1011230020
Q1 TRANSISTOR, N-CH, FET 12NF06 1016560001
Q2 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q3 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q4 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q5 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q6 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q7 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q9 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q10
TRANSISTOR, N-CH, FET 2N7002
1013080033
Q11 TRANSISTOR, N-CH, FET 2N7002 1013080033
Q12 TRANSISTOR, N-CH, FET 2N7002 1013080033
R1 RESISTOR 68, 5%, 1/8W 1013806808
R2 POT. 500, 10%, 3/4W, 15 TURNS 0338490078
R3 RESISTOR 8.66K, 1% 1/8W 1014730007
R4 RESISTOR 16.9K, 1% 1/8W 1014760003
R5 RESISTOR 3.74K, 1% 1/8W 1014690005
R6 RESISTOR 15.0K, 1% 1/8W 1014750008
R7 RESISTOR 5.76K, 1% 1/8W 1014710006
R8 RESISTOR 25.5K, 1% 1/8W 1014780004
R9 RESISTOR 68, 5%, 1/8W 1013806808
R10 POT. 500, 10%, 3/4W, 15 TURNS 0338490078
R11 RESISTOR 8.66K, 1% 1/8W 1014730007
R12 RESISTOR 16.9K, 1% 1/8W 1014760003
R13 RESISTOR 3.74K, 1% 1/8W 1014690005
R14 RESISTOR 15.0K, 1% 1/8W 1014750008
R15 RESISTOR 5.76K, 1% 1/8W 1014710006
R16 RESISTOR 25.5K, 1% 1/8W 1014780004
R17 RESISTOR, 10K, 1% 1/10W 1016420005
R18 RESISTOR 120K, 5%, 1/8W 1013801245
R19 RESISTOR 8.66K, 1% 1/8W 1014730007
R20 RESISTOR 16.9K, 1% 1/8W 1014760003
R21 RESISTOR 3.74K, 1% 1/8W 1014690005
R22 RESISTOR 15.0K, 1% 1/8W 1014750008
R23 RESISTOR 5.76K, 1% 1/8W 1014710006
R24 RESISTOR 25.5K, 1% 1/8W 1014780004
R25 RESISTOR 100K, 5%, 1/8W 1013801041
R26 RESISTOR, 10K, 1% 1/10W 1016420005
R27 RESISTOR, 10K, 1% 1/10W 1016420005
PC ASSEMBLY, Digital Audio Board Panel 3 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R28 RESISTOR, 10K, 1% 1/10W 1016420005
R29 RESISTOR, 10K, 1% 1/10W 1016420005
R30 RESISTOR 39K, 5%, 1/8W 1013803931
R31 RESISTOR, 10K, 1% 1/10W 1016420005
R32 RESISTOR 39K, 5%, 1/8W 1013803931
R33 RESISTOR, 10K, 1% 1/10W 1016420005
R34 RESISTOR, 10K, 1% 1/10W 1016420005
R35 RESISTOR, 10K, 1% 1/10W 1016420005
R36 RESISTOR, 10K, 1% 1/10W 1016420005
R37 RESISTOR 1M, 5%, 1/8W 1013801059
R38 RESISTOR, 10K, 1% 1/10W 1016420005
R39 RESISTOR, 10K, 1% 1/10W 1016420005
R40 RESISTOR 2.00K, 1% 1/8W 1014680000
R41 RESISTOR 8.66K, 1% 1/8W 1014730007
R42 RESISTOR, 10K, 1% 1/10W 1016420005
R43 RESISTOR, 10K, 1% 1/10W 1016420005
R44 RESISTOR, 10K, 1% 1/10W 1016420005
R45 RESISTOR 100K, 5%, 1/8W 1013801041
R46 RESISTOR, 10K, 1% 1/10W 1016420005
R47 RESISTOR, 10K, 1% 1/10W 1016420005
R48 RESISTOR, 10K, 1% 1/10W 1016420005
R49 RESISTOR, 10K, 1% 1/10W 1016420005
R50 RESISTOR 330, 5%, 1/8W 1013803311
R51 RESISTOR 56K, 5%, 1/8W 1013805631
R52 RESISTOR, 10K, 1% 1/10W 1016420005
R53 RESISTOR, 10K, 1% 1/10W 1016420005
R54 RESISTOR, 10K, 1% 1/10W 1016420005
R55 RESISTOR, 10K, 1% 1/10W 1016420005
R56 RESISTOR 33, 10%, 2W 0191800007
R57 RESISTOR 47, 10%, 2W 0163720002
R58
RESISTOR, 10K, 1% 1/10W
1016420005
R59 RESISTOR 100K, 5%, 1/8W 1013801041
R60 RESISTOR 8.66K, 1% 1/8W 1014730007
R61 RESISTOR 16.9K, 1% 1/8W 1014760003
R62 RESISTOR 3.74K, 1% 1/8W 1014690005
R63 RESISTOR 15.0K, 1% 1/8W 1014750008
R64 RESISTOR 5.76K, 1% 1/8W 1014710006
R65 RESISTOR 25.5K, 1% 1/8W 1014780004
R66 RESISTOR, 10K, 1% 1/10W 1016420005
R67 RESISTOR 33K, 5%, 1/8W 1013803337
R68 RESISTOR 8.66K, 1% 1/8W 1014730007
R69 RESISTOR 16.9K, 1% 1/8W 1014760003
R70 RESISTOR 3.74K, 1% 1/8W 1014690005
R71 RESISTOR 15.0K, 1% 1/8W 1014750008
R72 RESISTOR 5.76K, 1% 1/8W 1014710006
R73 RESISTOR 25.5K, 1% 1/8W 1014780004
R74 RESISTOR, 10K, 1% 1/10W 1016420005
R75 RESISTOR 33K, 5%, 1/8W 1013803337
R76 RESISTOR 8.66K, 1% 1/8W 1014730007
R77 RESISTOR 16.9K, 1% 1/8W 1014760003
R78 RESISTOR 3.74K, 1% 1/8W 1014690005
R79 RESISTOR 15.0K, 1% 1/8W 1014750008
R80 RESISTOR 5.76K, 1% 1/8W 1014710006
R81 RESISTOR 25.5K, 1% 1/8W 1014780004
R82 RESISTOR, 10K, 1% 1/10W 1016420005
R83 RESISTOR 15.0K, 1% 1/8W 1014750008
R84 POT. 10K, 10%, 3/4W, 15 TURNS 0338490043
R85 POT. 10K, 10%, 3/4W, 15 TURNS 0338490043
R86 RESISTOR, 10K, 1% 1/10W 1016420005
R87 RESISTOR 68K, 5%, 1/8W 1013806832
R88 RESISTOR, 10K, 1% 1/10W 1016420005
R89 RESISTOR, 10K, 1% 1/10W 1016420005
R90 RESISTOR 68K, 5%, 1/8W 1013806832
R91 RESISTOR, 10K, 1% 1/10W 1016420005
R92 RESISTOR 68K, 5%, 1/8W 1013806832
R93 RESISTOR 16.9K, 1% 1/8W 1014760003
R94 RESISTOR 8.66K, 1% 1/8W 1014730007
R95 RESISTOR, 10K, 1% 1/10W 1016420005
R96 RESISTOR 47K, 5%, 1/8W 1013804732
R97 RESISTOR 100K, 5%, 1/8W 1013801041
PC ASSEMBLY, Digital Audio Board Panel 4 of 7
Figure 8.15 1A2A3 Digital Audio Assembly
Parts List (Sheet 1 of 2)
To Next Page
Loading...
