RT-9000C Hardware Supplement
Document No. 8121000602
Revision A (19 Mar 2007)
8-48
RT-9000C
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R98 RESISTOR, 10K, 1% 1/10W 1016420005
R99 RESISTOR, 10K, 1% 1/10W 1016420005
R100 RESISTOR 100K, 5%, 1/8W 1013801041
R101 RESISTOR 100K, 5%, 1/8W 1013801041
R102 RESISTOR 100K, 5%, 1/8W 1013801041
R103 RESISTOR 100K, 5%, 1/8W 1013801041
R104 RESISTOR 15.0K, 1% 1/8W 1014750008
R105 RESISTOR 100K, 5%, 1/8W 1013801041
R106 RESISTOR, 10K, 1% 1/10W 1016420005
R107 RESISTOR 100K, 5%, 1/8W 1013801041
R108 RESISTOR 100K, 5%, 1/8W 1013801041
R109 RESISTOR, 10K, 1% 1/10W 1016420005
R110 RESISTOR, 10K, 1% 1/10W 1016420005
R111 RESISTOR, 10K, 1% 1/10W 1016420005
R112 RESISTOR, 10K, 1% 1/10W 1016420005
R113 RESISTOR, 10K, 1% 1/10W 1016420005
R114 RESISTOR, 10K, 1% 1/10W 1016420005
R115 RESISTOR 39K, 5%, 1/8W 1013803931
R116 RESISTOR 1K, 5%, 1/8W 1013801024
R117 RESISTOR 47K, 5%, 1/8W 1013804732
R118
POT. 1K, 10%, 3/4W, 15 TURNS
0338490019
R119 RESISTOR, 10K, 1% 1/10W 1016420005
R120 RESISTOR, 10K, 1% 1/10W 1016420005
R121 RESISTOR, 10K, 1% 1/10W 1016420005
R122 RESISTOR, 10K, 1% 1/10W 1016420005
R123 RESISTOR, 10K, 1% 1/10W 1016420005
R124 RESISTOR, 10K, 1% 1/10W 1016420005
R125 RESISTOR 1K, 5%, 1/8W 1013801024
R126 RESISTOR 1K, 5%, 1/8W 1013801024
R127 RESISTOR 1K, 5%, 1/8W 1013801024
R128 RESISTOR 1K, 5%, 1/8W 1013801024
R129 RESISTOR, 10K, 1% 1/10W 1016420005
R130 RESISTOR 1K, 5%, 1/8W 1013801024
R131 RESISTOR, 10K, 1% 1/10W 1016420005
R132 RESISTOR, 10K, 1% 1/10W 1016420005
R133 RESISTOR, 10K, 1% 1/10W 1016420005
R135 RESISTOR, 10K, 1% 1/10W 1016420005
R136 RESISTOR, 10K, 1% 1/10W 1016420005
R137 RESISTOR, 10K, 1% 1/10W 1016420005
R138 RESISTOR, 10K, 1% 1/10W 1016420005
R139 RESISTOR, 10K, 1% 1/10W 1016420005
R140 RESISTOR, 10K, 1% 1/10W 1016420005
R141 RESISTOR, 10K, 1% 1/10W 1016420005
R142 RESISTOR, 10K, 1% 1/10W 1016420005
R143 RESISTOR, 10K, 1% 1/10W 1016420005
R144 RESISTOR, 10K, 1% 1/10W 1016420005
R145 RESISTOR, 10K, 1% 1/10W 1016420005
R146 RESISTOR, 10K, 1% 1/10W 1016420005
R147 RESISTOR, 10K, 1% 1/10W 1016420005
R148 RESISTOR, 10K, 1% 1/10W 1016420005
R149 RESISTOR 560, 5%, 1/8W 1013805615
R150 RESISTOR 560, 5%, 1/8W 1013805615
R151 RESISTOR, 10K, 1% 1/10W 1016420005
R152 POT. 100K, 10%, 3/4W, 15 TURNS 0338490051
R153 RESISTOR 1, 10%, 1/2W 0194770001
R154 RESISTOR 47K, 5%, 1/8W 1013804732
R155 RESISTOR 47K, 5%, 1/8W 1013804732
R156 RESISTOR 47K, 5%, 1/8W 1013804732
R157 RESISTOR 47K, 5%, 1/8W 1013804732
R158 RESISTOR 5.11K, 1% 1/8W 1014700001
R159 RESISTOR 16.9K, 1% 1/8W 1014760003
R160 RESISTOR 1M, 5%, 1/8W 1013801059
R161 RESISTOR 560K, 5%, 1/8W 1013805640
R162 RESISTOR 560K, 5%, 1/8W 1013805640
R163 RESISTOR 3.74K, 1% 1/8W 1014690005
R164 RESISTOR 2.00K, 1% 1/8W 1014680000
R165 RESISTOR 3.74K, 1% 1/8W 1014690005
R166 RESISTOR 2.00K, 1% 1/8W 1014680000
R167 RESISTOR 3.74K, 1% 1/8W 1014690005
R168 RESISTOR 2.00K, 1% 1/8W 1014680000
PC ASSEMBLY, Digital Audio Board Panel 5 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
R169 RESISTOR 1.5K, 5%, 1/8W 1013801521
R170 RESISTOR 470, 5%, 1/8W 1013804716
R171 RESISTOR, 10K, 1% 1/10W 1016420005
R172 RESISTOR, 10K, 1% 1/10W 1016420005
R173 RESISTOR, 10K, 1% 1/10W 1016420005
R174 RESISTOR 5.11K, 1% 1/8W 1014700001
R175 RESISTOR 2.00K, 1% 1/8W 1014680000
R176 RESISTOR 5.11K, 1% 1/8W 1014700001
R177 RESISTOR 2.00K, 1% 1/8W 1014680000
R178 RESISTOR, 10K, 1% 1/10W 1016420005
R179
RESISTOR, 10K, 1% 1/10W
1016420005
R180 RESISTOR, 10K, 1% 1/10W 1016420005
R181 RESISTOR, 10K, 1% 1/10W 1016420005
R182 RESISTOR, 10K, 1% 1/10W 1016420005
R183 RESISTOR, 10K, 1% 1/10W 1016420005
R184 RESISTOR, 10K, 1% 1/10W 1016420005
R185 RESISTOR, 10K, 1% 1/10W 1016420005
S1 SWITCH, SPST, DIP, 3 POSITION 1016870001
S2 SWITCH, SPST, DIP, 3 POSITION 1016870001
S3 SWITCH, SPST, DIP 8 POSITION 1017160007
S4 SWITCH, SPST, DIP 8 POSITION 1017160007
T1 TRANSFORMER, MODEM V.90 1013280032
T2 TRANSFORMER, MODEM V.90 1013280032
T3 TRANSFORMER, MODEM V.90 1013280032
T4 TRANSFORMER, MODEM V.90 1013280032
T5 COMMON MODE CHOKE 23Z104SM 1016430001
TP1 TEST POINT, RED 1011130033
TP2 TEST POINT, RED 1011130033
TP3 TEST POINT, RED 1011130033
TP7 TEST POINT, RED 1011130033
U1 IC LINEAR MC34074 1014100003
U2 IC LINEAR MC34074 1014100003
U3 IC LINEAR MC34074 1014100003
U4 IC. LINEAR LM2903D 1015940005
U5 IC. DIGITAL, 4584 1016060009
U6 IC. DIGITAL, 74HC14 1016090005
U7 IC. DIGITAL, 74HC00 1016070004
U8 IC. DIGITAL, 74HC08 1016080000
U9 IC. LINEAR UDN2935Z 1010830007
U10 IC. LINEAR UDN2935Z 1010830007
U11 IC. DIGITAL, 75372D 1016300000
U12 IC. LINEAR LM1875T 1012120031
U13 IC LINEAR MC34074 1014100003
U14 IC LINEAR MC34074 1014100003
U15 IC LINEAR MC34074 1014100003
U16 IC. LINEAR, NE5532D 1016310005
U17 IC. DIGITAL, 4094 1016330006
U18 IC. DIGITAL, 4081 1016040008
U19 IC. DIGITAL, 4066 1016050003
U20 IC. LINEAR, SA571D 1016110006
U21 IC. DIGITAL, 4066 1016050003
U22 IC LINEAR MC34072 1014090008
U23 IC. DIGITAL, 4066 1016050003
U24 IC. DIGITAL, 4066 1016050003
U25 IC. DIGITAL, 4094 1016330006
U26 IC. DIGITAL, 4014 1016320001
U27 IC. DIGITAL, 4014 1016320001
U28 IC. DIGITAL, 4585 1016340001
U29 IC. DIGITAL, 4585 1016340001
U30 IC. DIGITAL, 4585 1016340001
U31 IC. DIGITAL, 4066 1016050003
U32 IC. DIGITAL, 4584 1016060009
U33 IC. DIGITAL, 4584 1016060009
U34 IC. DIGITAL, 4014 1016320001
U35 IC. LINEAR, REF3212 1016760001
U36 IC. LINEAR LM2903D 1015940005
U37 IC LINEAR MC34072 1014090008
U38 IC LINEAR MC34072 1014090008
U39 IC. DIGITAL, 4585 1016340001
U40 IC. DIGITAL, 4094 1016330006
PC ASSEMBLY, Digital Audio Board Panel 6 of 7
Ref
Symbol
Description
Sunair
Part No.
Notes/
Rev
U41 IC. DIGITAL, SN65LVDT2 1016740000
U42 IC. DIGITAL, SN65LVDT2 1016740000
U43 IC LINEAR, VOLT REG,LT1521-3.3 1015330002
U44 IC. DIGITAL, SN65LVDS047 1016750005
U45 IC LINEAR MC34072 1014090008
U46 IC. DIGITAL, 4081 1016040008
U47 IC. DIGITAL, 4504 1016880006
U48 IC. DIGITAL, 4504 1016880006
U49 IC. DIGITAL, 4081 1016040008
U50 IC. DIGITAL, 4014 1016320001
HEATSINK, SPEAKER DRIVER
8076092205
MOUNTING PLATE, DIGITAL AUDIO 8121091608
PC ASSEMBLY, Digital Audio Board Panel 7 of 7
Figure 8.15 1A2A3 Digital Audio Assembly – Parts List (Sheet 2 of 2)
