BASE ASSEMBLY INSTRUCTIONS
INCLUDES: 1 base panel, 2 side panels, 1 top panel, 1 front panel, 1 back panel and
12 screws (8 for assembly and 4 extras)
BACK PANEL
TOP PANELBASE PANEL
FRONT PANELSIDE PANELS
No. 0282
affix screws
affix screws
Once base is assembled and screws are
tightly fastened on base and top panels,
the unit can be placed on top. Be sure to
securely place the feet of the unit into the
grooves on the top panel of the base. The
unit and base should be aligned.
