Assembly
J
J
8.1
8.2
98
A
B
10 11
10. Lid (J) can be stored on hooks as indicated when re
pit is in use.
8. Turn assembled unit over to stand upright, pour ame
glass (H) around burner and put lid (J) in place.
11. Install Battery to Igniter (9). Remove the rubber cap
on the electronic igniter (A) by unscrewing and slide
battery (B) into the battery slot. Make sure the positive
side of the battery faces outwards. Screw the electronic
igniter cap (A) over the battery tightly.
8.1. Leave adequate space around the Ignition Screen
for ventilation.
8.2. DO NOT block or cover the Ignition Screen with
the ame glass.
Page 12
