Natural Gas
Conversion
supply piping system.
natural gas supply
piping system
natural gas hose
gas valve
3
4
5
inlet tube
NG air hole cover
bellows
Page 10
Hardware Used
Wrench
Hardware Used
Torque Wrench
4. Connect the natural gas hose with gas valve by
3. Connect the bellows with natural gas orifice by
screwing clockwise tightly using the wrench.
Then connect and tighten the natural gas orifice
with inlet tube using the wrench.
Natural gas orifice is painted with a black mark.
screwing clockwise tightly using the torque wrench.
Requires a CSA Certified NG Conversion
kit 50 000 BTUs and 3/8” NG Hose.
