Assembly
7. Pour the Flame Glass (K) around the burner. Ensure Flame Glass is
not placed or blocking the Ignition Screen of the burner.
8. Fire table assembly is now complete. At the bottom of legs, there are four
adjustable screws. Consumer can adjust the screws to an even height.
COMPLETELY. This will prevent water from accumulating in the Firebowl
9. Put the lid (L). then the Protective Cover (E) on the fire table when the
fire table is NOT in use or after use, when the fire table has cooles down
Pan and to protect exterior surfaces.
7
8
9
Page 12
Ignition Screen
DO NOT COVER THE IGNITION SCREEN when placing the
flame glass into the firebowl. Always keep ignition screen visible.
