J-2c. The
speed adjustment cam pin parts (137) may be loose. Take off rear cover (128)
and examine cam pin assembly. The Bakelite capped screw and square slot nut
should fit together snugly. If they do not, remove nut from screw, and pinch the
two sides of the nut against the slot with a pair of pliers, so that screw and
nut do make a snug fit.
J-2d. The governor
resistor (43) or governor condenser (140) may require rep1acement.
Remove governor assembly (100) according to Sections A-2 and A-3. Place a piece
of paper between the two governor contact points and touch test lamp wires to
the two resistor fastening screws on the back of the governor assembly. If
resistor (43) is in good order and condenser (140) is not shorted the test lamp
will light very dimly. But if resistor is open, the test lamp will not light at
all; and if the condenser is shorted, the lamp will light to full brilliance.
When either resistor or condenser need to be replaced, change only those parts;
it will not be necessary to replace the complete governor assembly.
J-2e. The
switch contact pressure may not be great enough. If switch spring lever
(105) should just barely make contact, the vibration of the motor may make the
switch contact unsteady and cause the motor to jerk. Bend up switch spring (105)
in the middle and down at the back end slightly, or replace switch pin (125) If
pin is short.
* * * * * * * *
The Tools Listed in This Bulletin are:
Tool No
.
T16023 For Set Screw in Worm Gear (P9922)
Standard Box End Wrench, Size 3/4 in.
Standard Spintite Wrench, Size 1/4 in.
Standard Screw Driver, length 6” blade width 3/32
Standard Extra deep Socket, Size 7/16 In.
Standard File (Automobile Distributor Point File)
Standard Adjustable pliers.
*Tools with T number - order from the factory.
Standard tools - purchase locally.
Sunbeam Corporation
5600 W. Roosevelt Rd.
Chicago 50, ILL. U.S.A.
