6
Reversing the Door
This refrigerator has the capability to either open from the right or left side. Should you wish to
reverse the opening direction, follow the directions below:
Note: All removed parts must be saved to reinstall the door.
Before reversing the door:
• Unplug the refrigerator from the power source.
• Empty the refrigerator contents, including shelves.
Tools Required:
• Putty knife
• Cross recess head screwdriver
To Reverse the Door:
1. Remove the upper and lower hinge covers on the right and left side.
2. Using a screwdriver, remove the six bolts at the top and bottom of the cabinet.
3. Remove the upper and lover hinges and remove the door. Set on a padded surface to
prevent scratching.
4. Transfer the hinges and bolts to the opposite side of the refrigerator, ensuring the upper
hinge pin goes into the upper door hole.
5. Tighten the three bolts at the top and three on the bottom.
6. Insert the hinge covers.
