21
Shed Assembly/Headers and Truss
Place front header (J) over door opening and t four
protruding support legs into pockets molded in front
corners. Secure front header using two screws (JJ).
Place rear header (K) over back walls and t four
protruding support legs into pockets molded in back
walls. Secure rear header using seven screws (JJ).
Slide truss assemblies into place. Secure with four
screws (JJ) in each side adaptor bracket.
Raise ridge beam (V/EEE) up and into rear header (K).
Secure with one bolt (MM) and one nut (LL). DO NOT
tighten. Repeat for front header (J).
Note: Header panels may need to be pushed inwards or
outwards slightly as ridge beam is slid into place.
