22
Shed Assembly/Headers and Truss (continued)
Attach truss strap (GG) to side adaptor bracket (FF) with
two screws (JJ).
Repeat for remaining truss straps.
Shed Assembly/Roof
Before proceeding, locate and identify the six slots on
interior side of right and left roof panels.
Attach the roof truss assembly to the ridge beam with
two screws (JJ).
To Next Page
