Suncast Covington BMS7425 - Page 13

13
Slide roof ridge beam bracket (V) under tabs on inside
peak of front header (J) and secure with two screws (KK).
DO NOT over tighten screws.
Place header vent (R) into front opening in front header
(J). Secure through back of header with four screws (LL).
DO NOT over tighten screws.
1
2
5
x2
J
KK
V
1
1
2
6
x4
J
LL
R
Header Pre-Assembly
2
7
x6
J
KK
X
X
Lay front header (J) on ground with lettering side facing
up. Place one header beam (X) into pocket on inside of
front header. Attach with six screws (KK). DO NOT over
tighten screws.
Repeat steps 5-7 for rear header (K).
