Shed Assembly/Roof (continued)
Lay right roof (L) directly over three tabs on right side
of front header (J). With right roof slots seated over/on
header tabs, check alignment in all three spots.
Slide right roof (L) down towards the outside of shed.
You will hear a "snap" when engaged.
x4x4
2
2
1
1
25
L
KK
Pull down each lower corner of right roof (L) from
outside. From inside shed, attach each tab to the
corresponding roof panel with one screw (KK).
1
1
1
1
1
1
1
x6x6
2
26
M
J
x4x4
2
2
1
1
27
M
KK
Pull down each lower corner of left roof (M) from
outside. From inside shed, attach each tab to the
corresponding roof panel with one screw (KK).
Lay left roof (M) directly over the three tabs on left side
of front header (J). With left roof slots seated over/on
header tabs, check alignment in all three spots.
Slide left roof (M) down towards the outside of shed.
You will hear a "snap" when engaged.
