1.1 Main specification
3
1. Input Spec. (MULTI VIDEO INTERFACE)
-. 1 x Analog R,G,B (Sync on Green)
-. 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
- 3 x A/V (NTST & PAL) Input.
-. 1 x LCD Input (Car system Input)
2. Output Spec.
-. 2 X CVBS OUTPUT (Video Out for installing Headrest monitor)
-. 1 x Audio OUTPUT
-. 1 X LCD OUTPUT(LCD Operation)
3. Electric Power Consumption
- Input Power : 8VDC ~ 24VDC
- Consumption Power : 12WATT, Max
4. Switching Mode (AV source)
- Possible to skip AV source by switching Mode (AV source) in DIP S/W
(Refer to the DIP S/W page)
- By ‘SET’ button of the OSD Keypad and Remote Control
- By Toggle Switch (Option)
- By ‘Menu’ button of the car through CAN
