5221 and 5222 6 2/3/20
Hydraulic Ram
* Hydraulic Ram Repair Kit, RS5221HRRK for 5221 unit. ** Hydraulic Ram Repair Kit, RS5222HRRK for 5222 unit.
Only Index No.'s identified by Part No. are available individually.
1 Ram Base 1
2 Screw 2
3 * , ** O Ring 6X3 2
4 Spring 2
5 Spring Base 2
6 * , ** Steel Ball 4 2
7 * , ** Steel Ball 6 5
8 * , ** Sealing Ring 1
9 Release Valve 1
10 Bottom Plate 1
11 * O Ring 28x3.55 1
** O Ring 33.5x3.55 1
12 * Washer 36x4.4 1
** Washer 40x4.4 1
13 Piston Ring 1
14 Retaining Ring 1
15 Piston 1
16 Oil Tank 1
17 * Bottom Sealing Ring 76x71x4 1
** Bottom Sealing Ring 81x76x4 1
18 * , ** Oil Refill Cap 1
19 Reservoir 1
20 * , ** Top Sealing Ring 64x58x1 1
21 * O Ring 31.5x3.55 1
** O Ring 33.5x3.55
22 Top Nut 1
23 * , ** Sealing Ring 2
24 Pump Piston Housing 12x55 2
25 * , ** O Ring 6.6x3 2
26 * , ** O Ring 12x7x1.5 2
27 Pump Piston 12x68 2
28 Handle Yoke 1
29 Linkage Rod 1
30 Pin 8x25 3
31 R-Pin 3
32 Handle 1
33 Handle Cap 1
34 Washer 10 1
35 Spring Washer 10 1
36 Hex Bolt M 10x25 1
PARTS LIST AND DRAWING
Ref No. Part No. Description Qty Ref No. Part No. Description Qty
5221 and 5222
CAPACITY: 1 and 2 TON
FOLDABLE ENGINE CRANES
