PARTS LIST
* Available as hardware Kit: RS66715HK
Only items identified by part number are available for purchase.
REF # PART# DESCRIPTION QTY
1 RS6671501 Rubber Saddle Pad 1
2 Saddle Bolt (incl. with #3) 1
3 RS6671503 Saddle Assembly 1
4 Lifting Arm Assembly 1
5 Front Wheel Axle 1
6 RS6671506 Handle Hook Assembly 1
(incl. #7-11, 15, 16)
7 Washer (incl. with #6) 1
8 Hook Base (incl. with #6) 1
9 Locking Nut (incl. with #6) 1
10 Nut (incl. with #6) 1
11 Spring Washer (incl. with #6) 3
12 RS6671512 Front Wheel Assembly (incl. #13, 14) 2
13 Front Wheel Washer (incl with #12) 2
14 Locking Nut (incl. with #12, 26) 4
15 Bolt (incl. with #6) 1
16 Bolt (incl. with #6) 3
17 Axle 1
18 Bolt 2
19 Guide Arm 2
20 Locking Nut 2
21 Flat Washer 2
22 Spring Washer (incl. with #49) 6
23 * Spring Washer 8
24 * Bolt 2
25 Bolt 6
26 RS6671526 Rear Caster Assembly (incl. with #14) 2
27 * Washer 2
28 Yoke Axle 2
29 * Cotter Pin 1
30 * Retaining Ring 2
31 RS6671531 Lifting Arm Return Spring 2
REF # PART# DESCRIPTION QTY
32 Truion 2
33 RS6671533 Power Unit Assembly 1
34 RS6671534 Release Assembly 1
35 * Washer (incl. with #36, 49) 2
36 RS6671536 Pump Roller Assembly 1
(incl. with #35, 37)
37 Pump Roller Axle (incl. with #36) 1
38 RS6671538 Lower Yoke Section 1
39 RS6671539 Handle Assembly (incl. with #40-42) 1
40 RS6671540 Spring Lock (incl. with #39) 1
41 Upper Handle (incl. with #39) 1
42 RS6671542 Handle Grip (incl. with #39) 1
43 Lock Clip (incl. with #49) 1
44 Rivet (incl. with #49) 1
45 Bolt (incl. with #49) 1
46 Retaining Ring (incl. with #49) 1
47 Spring (incl. with #49) 1
48 Short Axle (incl. with #49) 1
49 RS6671549 Upper Yoke Assembly 1
(incl. #22, 35, 43-48)
50 Trunion Arm 2
51 Bolt 4
52 Axle 1
53 Rubber Washer 2
54 Lifting Arm Pivot Pin 1
55 * Retaining Ring 2
56 Bolt 2
57 Grab Handle 1
RS66715FASJPLK Product Label Kit (not shown) 1
66175FASJ
CAPACITY: 3500 LB.
FOLDING ALUMINUM SERVICE JACK
