U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18) Page 13
SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
DOOR COMPONENTS & ASSEMBLIES
ITEM PART# DESCRIPTION QTY
CRITICAL
1 1534500 Seal - Door, Bottom 1
2 G03269R Seal - Door, Top / Left / Right (sold by the foot)
TOP  3’
L/R  2’ EACH
3 1304201 Side Door Bracket - S/S, Left 1
4 1304202 Top Door Bracket - S/S 1
5 1719001 Right Door Seal 1
6 4515192
Center Door Seal - Right
Note: Used FROM 1-Jan-2003.
1
7 4515191
Center Door Seal - Left
Note: Used FROM 1-Jan-2003.
1
8 8003123 #10-24 x 5/8” Machine Screw, Phillips, Stl (for Center Door Seals) 6
9 1021904
Door Catch (Door)
Note: Used UP TO 22-May-2003.
1 C
10 1021902
Door Catch (Frame)
Note: Used UP TO 22-May-2003.
1 C
Door Chain Assembly & Components
15 4520166
Door Chain Assembly
Note: Includes Items 16 - 20
2 C
16 1014201
Connecting Door Rod - Short
Note: Item listed for reference only. Not Sold Separately.
2 C
17 1014200
Connecting Door Rod - Long
Note: Item listed for reference only. Not Sold Separately.
2 C
18 1015000 Turnbuckle 1/4-20 with 4" Take Up 2 C
19 1021100 Roller Chain #40 2
20 1021299 Connecting Link #40 4
Door Micro Switch & Related Components
21 1019600 Door Micro Switch 1 C
22 1533400 Door Micro Switch - Cover 1
23 1533800 Door Micro Switch - Bracket 1
Left and Right Doors Components
31 1562602 (Old Style) Door Handle End - Top, Grey
Note:
(Old Style) Used UP TO
Mar-2003.
1
32 1562603 (Old Style) Door Handle End - Bottom, Grey 1
33 1664800 (Old Style) Door Handle - Grey 1
34 1663201 Handle Bracket Plate (for Old Style Handle) 1
35 4518768 Door Handle Tube with Insert, Painted 1
36 1924206 Plate for Door Handle 2
37
1011605
Door Panel - Left
Note: Used UP TO Mar-2003.
1
4515200
Door Panel - Left
Note: Used From Mar-2003
1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
