U_GO_PL_SUNFIRE_SDG1SDG2 (Rev 18)Page 14
SUNFIRE PARTS IDENTIFICATION
Gas Convection Ovens models SDG-1, SDG-2
DOOR COMPONENTS & ASSEMBLIES
ITEM PART# DESCRIPTION QTY
CRITICAL
38
1011895
Door Frame Assembly - Left
Note: Used UP TO 26-Mar-2003
1
CK4515197
Door Frame Assembly - Left
Note: Used From 27-Mar-2003
1
39
1011799
Liner - Left Door
Note: Used UP TO Mar-2003
1
4515203
Liner - Left Door
Note: Used From Mar-2003
1
40 1010999 Oven Door Window - 3/16” Glass 2
41 1923201 Spacer - Door Hinge 2
42 CK1010589 Hinge Bracket Assembly with Bearing 1
43 1302800 Upper Door Bearing Retainer 2
44 0010000FG Fiberglass Insulation 2
51
4515206 Door Panel - Right (Window) 1
1011402 Door Panel - Right (Solid) 1
52
CK4515196 Door Frame Assembly - Right (Window) 1
1011897 Door Frame Assembly - Right (Solid) - No Longer Available
53
4515209 Liner - Right Door (Window) 1
1011582 Liner - Right Door (Solid) 1
Left Door - Complete Assemblies
60
CK1029279
Left Door Assembly (Window)
Note: Used UP TO 26-Mar-2003.
1
CK1029277
Left Door Assembly (Solid)
Note: Used UP TO 26-Mar-2003.
1
CK4515199
Left Door Assembly (Window)
Note: Used FROM 27-Mar-2003.
1
Right Door - Complete Assemblies
61
CK1029276
Right Door Assembly (Window)
Note: Used UP TO 26-Mar-2003.
1
CK1029278
Right Door Assembly (Solid)
Note: Used UP TO 26-Mar-2003.
1
CK4515198
Right Door Assembly (Window)
Note: Used FROM 27-Mar-2003.
1
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
