Sungrow SBR Series User Manual

GD_202111_Sungrow SBR HV Battery Installation Quick Guide with SHRT _V3.0
Page 2 of 6
© Sungrow Australia Group Pty. Ltd. All rights reserved.
As we continuously improving our services, changes to this document may occur without notice.
Sungrow SBR HV Battery Installation Tips
Installation requirements:
Sungrow recommends that the shaded side of the building would be better to prevent
the battery from exposure to the sun, rain, and snow. Battery must not be mounted
in direct sunlight as this affects the internal heat, and therefore efficiency of the
battery and warranty.
Minimum clearances:

Sungrow SBR Series Specifications

General

Battery Type	Lithium iron phosphate (LFP)
Nominal Voltage	51.2 V
IP Rating	IP65
Cooling	Natural convection
Operating Temperature Range	-10°C to 50°C
Communication	CAN
Protection Level	IP65
Cycle Life	>6000 cycles (70% EOL)
Communication Interface	CAN
