Sungrow SBR Series User Manual

GD_202111_Sungrow SBR HV Battery Installation Quick Guide with SHRT _V3.0
Page 3 of 6
© Sungrow Australia Group Pty. Ltd. All rights reserved.
As we continuously improving our services, changes to this document may occur without notice.
Installation process - SBR128 (4 modules) as an example
1. Screw feet in (Optional and to be available in Q4 2021).
2. Place the base at the acceptable position in right way (arrows outward).
3. Stack up battery modules.
4. Insert BMU (make sure the DC MCB is off) and screw in.

Sungrow SBR Series Specifications

General

Battery Type	Lithium iron phosphate (LFP)
Nominal Voltage	51.2 V
IP Rating	IP65
Cooling	Natural convection
Operating Temperature Range	-10°C to 50°C
Communication	CAN
Protection Level	IP65
Cycle Life	>6000 cycles (70% EOL)
Communication Interface	CAN
