Product Description
This chapter describes the exterior appearance and main components of the transformer.
2.1 Four Views
MVT of SG4400UD-MV-US as reference, The four views of the transformer are shown in the
figure below.
figure 2-1 Four Views of SG4400UD-MV-US
2.2 Exterior Dimensions
The dimensions of the transformer are shown in the figure below.
