Know Your Electric Pressure Washer
Read the owner’s manual and safety rules carefully before operating the pressure washer. Compare the illustration below
to the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
1. Trigger gun
2. On/O switch
3. Water outlet/high-pressure hose
connection
4. Garden hose adapter/
connection
5. Power cord with GFCI
6. Wheels (2)
7. Needle clean-out tool
8. Cord holder
9. Top handle
10. High-pressure hose holder
11. High-pressure hose
12. On-board nozzle storage
13. 0º Quick-Connect nozzle (red)
14. 15º Quick-Connect nozzle (yellow)
15. 40º Quick-Connect nozzle (gray)
16. Foam adjusting cap
17. Detergent nozzle
18. Foam cannon bottle
19. Spray wand protector
20. Brass quick-connect collar
21. Spray wand
22. Trigger gun holder
23. High-pressure hose connection
24. Trigger
25. Safety lock
