Sunjoy CHATHAM - Assembly Step 2: Roof Panel Installation; Attaching Side Roof Panels (Fig. 14-1, 14-2); Installing Roof Panel Covers (Fig. 15-1, 15-2)

AA 1/4"-20X0.6 Bolt 44 PCS
BB Φ1/4" Bigger flat washer 60 PCS
EE 1/4"-20X1.4 Bolt 16 PCS
Hardware Pack 2
Fig. 14-1: Attach Long side left roof panel (C3) to Long side left roof panel (E3) as one piece.
Fig. 14-2: Attach Long side left roof panel (C3) and Long side left roof panel (E3) to assembled top frame by using
bolt (AA) and washer (BB). (Use the same way to assemble D3, F3, G3, H3, I3, J3, K3, L3 and M3 respectively.)
Fig.15-1: Insert one end of Big roof panel cover (N3) into the hole of Small top slanting bar (C1).
Fig.15-2: Attach another end of Big roof panel cover (N3) to Big top slanting bar (A3) by using bolt (EE) and
washer (BB). (Use the same way to assemble Big roof panel cover (O3) to Big top middle beam (B3).
