Sunjoy Monterey - Step 3: Roof Structure and Canopy Attachment

HH Φ8X260MM Peg 16 PCS
GG Plastic tie 104 PCS
Hardware Pack 3
Fig.7: Attach Corner connector (H) to Pole (A) by using Bolt (AA) and Flat washer (BB).
Fig.8: Hang up the Hook (X) to Big Top Connector (Q). Then Insert Big top beam (L), Long side beam (N)
and Short side beam (M) into Big top connector (Q).
Fig.9: Insert Big top beam (L) into Corner connector (I).
Fig.10: Attach Side beam M (N) to Side beam connector (J) by Bolt (EE), Flat washer (BB) and Nut (FF).
Fig.11: Insert Small top bar (S) into Small top connector (R). Put on the Small canopy (T).
Fig.12: Put on the Large canopy (U), do not spread. Attach the small top to Big top beam (L) by Bolt (EE),
Flat washer
(
BB
),
Nut
(
FF
)
.
