SunPower SPR-E Series User Manual

SUNPOWER CORPORATION
Safety and Installation Instructions - Document 001-15497 Rev U
©September 2020 SunPower Corporation. All rights reserved. Specifications included in this manual are subject to change without notice.
Platform Module mounting and ground hole detail Frame Profile
FOR P-SERIES COMMERCIAL GEN 4.1 FRAME MODULES
Commercial
Modules
SIDE FRAME PROFILE
END FRAME PROFILE
FOR P-SERIES COMMERCIAL GEN 4.2 FRAME MODULES
Commercial
Modules
SIDE FRAME PROFILE
END FRAME PROFILE
FOR 104c GEN 4.2 FRAME MODULES
Commercial
Modules
SIDE FRAME PROFILE
END FRAME PROFILE
998 mm
46 mm
MODEL: SPR-P19-410-COM Rated Power (Pmax)
1
(+5/
0
%) 410
W
Voltage (Vmp) 43.9
V
Current (Imp) 9.35
A
Open-Circuit Voltage (Voc) 53.1
V
Short-Circuit Current (Isc) 9.94
A
Maximum SeriesFuse 15
A
1
Standard Test Conditions: 1000 W/m
2
, AM 1.5, 25° C
Suitable for ungrounded, positive, or negative grounded DC systems Field Wiring: Cu wiring only, min. 12 AWG/4 mm
2
, insulated for 90° C min.
WARNING
SEVERE ELECTRICAL HAZARD
• Solar module has full voltage even in very low light. • Installation should only be done by a qualified technician. 527040
www.sunpower.com
Patented as shown at www.sunpower.com/patents
Safety Class II Fire Rating: Class C
Max. System Voltage:1500 V DC
954 mm 961 mm
2067 mm
300 mm
400 mm
539 mm
1058 mm
1200 mm
1423 mm
1606 mm
4X Ø 4.2mm
Ground Holes
20X Ø 6.8mm
Mounting Holes
4X 5.0mm (W) x 15.0mm (L)
SLOT
998 mm
40 mm
MODEL: SPR-P19-410-COM Rated Power (Pmax)
1
(+5/
0
%) 410
W
Voltage (Vmp) 43.9
V
Current (Imp) 9.35
A
Open-Circuit Voltage (Voc) 53.1
V
Short-Circuit Current (Isc) 9.94
A
Maximum SeriesFuse 15
A
1
Standard Test Conditions: 1000 W/m
2
, AM 1.5, 25° C
Suitable for ungrounded, positive, or negative grounded DC systems Field Wiring: Cu wiring only, min. 12 AWG/4 mm
2
, insulated for 90° C min.
WARNING
SEVERE ELECTRICAL HAZARD
• Solar module has full voltage even in very low light. • Installation should only be done by a qualified technician. 527040
www.sunpower.com
Patented as shown at www.sunpower.com/patents
Safety Class II Fire Rating: Class C
Max. System Voltage:1500 V DC
954 mm 961 mm
2067 mm
400 mm
539 mm
1058 mm
1200 mm
1423 mm
1606 mm
4X Ø 4.2mm
Ground Holes
18X Ø 6.8mm
Mounting Holes
4X 5.0mm (W) x 15.0mm (L)
SLOT
32mm
40 mm
24 mm
40 mm
4x Ø 4.2 mm
Ground Holes
8x Ø 6.8 mm
Mounting Holes
1690 mm
1500 mm
1300 mm
1100 mm
1046 mm
1002 mm
32mm
40 mm
24 mm
40 mm
