50
MAIN INDICATION SCREEN
The menu indication screen shows the setting content and sub-menus for selected main menu. There is a list
of 14 settings in the setting contents. Four will be listed at a time. Press CURSOR UP or DOWN key on the
LCD to move to another screen.
SPEED : 0[RPM]
0/ 1991[00%]
TOTAL :258051[ST]
NEEDLE : 1[6] 1
SPEED: Indicates the present speed of the machine.
0/1991/[00%]: The percentage of the selected design that has been
completed.
TOTAL: The total number of stitches in memory at present.
NEEDLE: Needle bar in use at the present time.
NO: Indicates the location of the selected design in memory.
STITCH: The total number of stitches in the selected design.
COLOR: Number of color changes (needle bars) in the design.
JUMP: Number of JUMP stitches in the design.
NO. : 8
STITCH : 16850
COLOR : 6
JUMP : 118
To Next Page
