SunSynk SUN-BATT-5.12 Product Description

Page | 7 Hybrid Inverter | Installer Manual
Charging Battery Level Indicators Instructions:
Status Charging
Battery Level Indicator
L8 L7 L6 L5 L4 L3 L2 L1
Battery
Level
( %)
0 ~ 17%
Light OFF
OFF OFF OFF OFF OFF Flash 2
18 ~ 33% OFF OFF OFF OFF Flash 2 Light
34 ~ 50% OFF OFF OFF Flash 2 Light Light
51 ~ 66% OFF OFF Flash 2 Light Light Light
67 ~ 83% OFF Flash 2 Light Light Light Light
84 ~ 100% Flash 2 Light Light Light Light Light
Full Charged Light Light Light Light Light Light
Discharging Battery Level Indicators Instructions:
Status Discharge
Battery Level Indicator
L8 L7 L6 L5 L4 L3 L2 L1
Battery
Level
( %)
0 ~ 17%
Flash 3 OFF
OFF OFF OFF OFF OFF Light
18 ~ 33% OFF OFF OFF OFF Light Light
34 ~ 50% OFF OFF OFF Light Light Light
51 ~ 66% OFF OFF Light Light Light Light
67 ~ 83% OFF Light Light Light Light Light
84 ~ 100% Light Light Light Light Light Light
Full Charged Light Light Light Light Light Light
2.2.3. CAN / RS485 Port
CAN / RS485 Communication Terminal (RJ45 port), connect to inverter, follow CAN / RS485
protocol.
PIN Definition
Pin 1, Pin 8 RS485-B ( to PCS, reserved )
Pin 2, Pin 7 RS485-A ( to PCS, reserved )
Pin 3 NC
Pin 4 CANH ( to PCS )
Pin 5 CANL ( to PCS )
Pin 6 GND
