SUN-BATT-5.12R | User Manual8
Status
RUN ALM Battery Level Indicator
Discriptions
L8 L7 L6 L5 L4 L3 L2 L1
Shut down OFF OFF OFF OFF OFF OFF OFF OFF All OFF
Standby Flash 1 OFF According to the battery level Indicates Standby
Charging
Normal Light OFF According to the battery level
The highest capacity
indicator LED ashes
(ash 2),others lighting
Full
Charged
Light OFF Light Light Light Light Light Light
Turn to standby status
when charger o
Protection OFF Light OFF OFF OFF OFF OFF OFF Stop charging
Dis-
charge
Normal Flash 3 OFF According to the battery level
UVP OFF OFF OFF OFF OFF OFF OFF OFF Stop charging
Protection OFF Light OFF OFF OFF OFF OFF OFF Stop discharge
Fault OFF Light OFF OFF OFF OFF OFF OFF
Stop charging and
Discharge
Charging Battery Level Indicators Instructions:
Status Charging
Battery Level Indicator
L8 L7 L6 L5 L4 L3 L2 L1
Battery Level
( %)
0 ~ 17%
Light OFF
OFF OFF OFF OFF OFF Flash 2
18 ~ 33% OFF OFF OFF OFF Flash 2 Light
34 ~ 50% OFF OFF OFF Flash 2 Light Light
51 ~ 66% OFF OFF Flash 2 Light Light Light
67 ~ 83% OFF Flash 2 Light Light Light Light
84 ~ 100% Flash 2 Light Light Light Light Light
Full
Charged
Light Light Light Light Light Light
Discharging Battery Level Indicators Instructions:
Status Discharge
Battery Level Indicator
L8 L7 L6 L5 L4 L3 L2 L1
Battery Level
( %)
0 ~ 17%
Flash 3 OFF
OFF OFF OFF OFF OFF Light
18 ~ 33% OFF OFF OFF OFF Light Light
34 ~ 50% OFF OFF OFF Light Light Light
51 ~ 66% OFF OFF Light Light Light Light
67 ~ 83% OFF Light Light Light Light Light
84 ~ 100% Light Light Light Light Light Light
