2.3 Cabling example with FOX-100
Display of battery voltage and
charge current display
Fuse
FOX-D1
INB B
Charge controller
FOX-100
Solar module
battery 1
Note:
To avoid a detrimental total discharge of the battery,
the consumers must be switched off when the battery
voltage is 10.5V (or 21.0V with 24V systems).
Solar
Battery
Fuse
100 %
75 %
50 %
10
Solar Battery
1
Fuse
FOX 100
FOX 100
