Standard components of a PV system
Depending on the recommendations
of your electrician, your PV system will
consist of the following components:
PC
(3)
INVERTER
PV
PV
(1)
(2)
(4)
GRID
PV generator switch:
Designed as DC load break cut-out to cut
off the PV generator from the solar inverter.
Dimensioning: min. 900 V, ≥ 16 A
Grid connection:
3-phase (Feed-in: 1-phase; grid monitoring:
3-phase)
Standard components of the PV system
97
(1) PV generator switch
(2) Irradiation sensor with
integrated temperature
sensor
(3) Mains fuse
(4) Energy meter
