3.1 Monitoring and diagnosis
Display
The dot matrix LCD display is integrated
into the cabinet of the solar inverter so
that it is easily visible. The display consists
of 16 characters and 2 lines. The top line 1
shows the current feed-in power of the
solar inverter. The bottom line 2 outputs
operating data. The data can be displayed
in the German, English, French, Spanish or
Italian language.
* if the optional irradiation sensor with
integrated temperature sensor is connec-
ted
EN
Line 1 Current fed-in power Power kW
Line 2 AC voltage U-AC V
DC voltage U-DC V
Daily yield W-DAY Wh
Total yield W-TOT kWh
Irradiation * SOLAR W/m
2
PV generator temperature * TEMP-PAN °C
Time TIME
125
