Threading capacity
1/2” - 4” (Threading, cutting, reaming)
Voltage
CA 22OV 50/60 Hz
Motor
Single phase 1.2kW condenser motor
Rotation speed
11,20, 36 r.p.m
Net weight
49 kg
Dimensions
873(L) x 635(W) x 558(H) mm
Standard specifi cations
Accesories
Die head
Uni-auto V(1/2 - 2”), Profi ling die head(21/2” - 4”)
Dies
(1/2 - 3/4”), (1 - 2”), (21/2” - 4”) one set each
Stand
3 legs
Tool box
Hexagonal keys : 3, 4, 5, 6, 8 mm 5pcs.
Screwdriver : Cross point 1pc.
200mm Adjustable wrench 1pc.
Machine cover : 1pc.
Leg stand : 4pc.
GB
Name of each part/standard specifications/accessories
Fig. 1
Reamer
Head wheel
Rear chuck
Speed change lever
Switch
Leg
Tool box
Carriage handle
Cutter
Die head
PRECAUCION
The machine is designed for cutting, threading and reaming of pipes, as well as for tapping solid work
pieces.
Thread sealing and the mounting/removing of pipe fi ttings should not be performed.
