5
•Model
•SE Specication
Testing Fluid: Water
(
SG
1.0)
50HZ/60HZ
SE - 25 SK - 1/2 6 N F - C C H
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10)
(1) TYPE -SE
(2) In-Outlet
25-1" 40-1.5"
(3) Specic Gravity
SK - 1.1
(4) Power (HP)
1/2-1/2HP
3/4-3/4HP
1-1HP 2-2HP
(5) Frequency
5-50HZ, 6-60HZ
(6) Elastomer
V - VITON
N - NBR
E - EPDM
(7) Material
F - FRPP
K - PVDF
(8) Fixed-seal
C - Ceramic
S - SSIC
(9) Rotational-seal
C - Carbon
S - SSIC
(10) Bellows Spring
H - Hastelloy - C
S - SUS316
a
b
c
d
e
f
•SE Performance Curves
Model
In/Outlet
(mm)
Power 50HZ 60HZ
Weight
kg
In Out Phase HP kW Curve
Max.Head
M
Max.Flow
L/min
Curve
Max.Head
M
Max.Flow
L/min
25SK-1/2 25 25 3ø 1/2 0.4 a 7.5 155 A 11 160 19
40SK-1/2 40 40
3ø 1/2 0.4 b 8 185 B 11 190 19
25SK-3/4 25 25
3ø 3/4 0.6 c 9.5 175 C 13 190 20
40SK-3/4 40 40
3ø 3/4 0.6 d 8 195 D 13 230 20
40SK-1 40 40
3ø 1 0.75 e 11 225 E 15 250 21
40SK-2 40 40
3ø 2 1.5 f 14.5 260 F 25 320 29
