2IN-ROOF-K-TRX4-003
Use hand tools only when assembling.
Do not use power tools.
M6-1.0 Nylock Nut10x
(Kit Contents continued)
M12-1.75 x 30mm Lg. BHCS2x
M12-1.75 Nylock Nut2x
When installing components, do not tighten any hardware completely unless noted.
M6-1.0 x 20mm Lg. BHCS
22x
2x - Velcro Clamp
Flat Seal
Foam
M6-1.0 x 25mm Lg. BHCS10x
Small Clamp x 5
(UC-1.875)
Large Clamp x 6
(UC00-001)
Rubber must face plastic when
installing Sealing Washers
M6
10x
1/2”
2x
#14
22x
Sealing Washers
To Next Page
