Page 19
#4400 PARTS LIST
ITEM DESCRIPTION PART NO. QTY. MATERIAL
A FIFTH WHEEL PLATE ASSEMBLY 3601 1
B ROCKER ARM 3302 1 (See assembly components below in hardware kit)
C TURNTABLE CAM ARM 4403 1
C1 ROLLER FLANGE NUT 98150203 1 3/4”-16 HEX JAM NUT
C2 ROLLER 410304 1 (Roller Assembly)
C6 PLASTIC WEAR PLATE KIT 4412 1 MOLDED PLASTIC WEAR PLATES
D TURNTABLE WAY TUBES 44130001 2
E THREADED STOP ASSEMBLY 440501 1
E1 THREADED STOP JAM NUT 98150141 1 5/8” - 11 HEX JAM NUT
E2 THREADED STOP BOLT 98010219 1 5/8”-11 X 2-1/2” TAP BOLT
HARDWARE KIT -- 4110
B1 ROCKER ARM CLEVIS PIN 98410111 2 1-2” X 2” CLEVIS PIN
B2 PIN CLIP 98410127 6 #3 COTTER PIN
B3 ROCKER ARM SPRING 35100001 1 16 GA SPRING STEEL
B4 ROCKER ARM SPRING FLAT WASHER 98250160 1 5/16” ZINC FLAT WASHER
B5 ROCKER ARM SPRING LOCK WASHER 98200159 1 5/16” ZINC SPLIT LOCK WASHER
B6 ROCKER ARM SPRING BOLT 98010244 1 5/16”-18 X 1” HHCS GRD 5
C3 ROCKER ARM PIVOT BOLT 98010147 1 3/4” - 10 X 7” HHCS GRD 5
C4 PIVOT BOLT HEX NUT 98150131 1 3/4” - 10 SAE ZINC HEX NUT
C5 PIVOT BOLT LOCK WASHER 98200124 1 3/4” ZINC PLATED SPLIT LOCK WASHER
D1 WAY TUBE BOLT 98010167 4 1/2”-13 X 1-1/2” HHCS GRD. 5
D2 WAY TUBE FLAT WASHER 98250147 4
D3 WAY TUBE FLANGE NUT 98150201 4 1/2” - 13 ZINC, SERRATED FLANGE NUT
D4 HITCH PIN 08060001 4 1/2” ROUND
BASE RAIL KIT
BASE RAILS ARE DIFFERENT FOR EACH APPLICATION AND ARE SOLD SEPARATELY. CALL (800) 443-2307 FOR MORE INFORMATION.
