Superior IO-360 SERIES User Manual

Installation & Operation Manual
O-360 and IO-360 Series Engines
© March 2004 Superior Air Parts Inc. Chapter 1 • Engine Description
8
Figure 1-5 • O-360 Engine Rear View
MANIFOLD
PRESSURE
CONNECTION
OIL FILTER
BREATHER
FITTING
ALTERNATE OIL TO COOLER
OIL TEMP
CONNECTION
EYE
BRACKET
TACHOMETER CONNECTION
VACUUM PUMP / ACCESSORY PAD
OIL PRESSURE GAGE CONNECTION
OIL LEVEL TUBE & GAGE
GROUND OR “P-LEAD” TERMINAL
OIL SUPPLY TO COOLER
OIL LINE TO
PROPELLER
COMMON PRIMER
LINE SOURCE
FUEL PUMP INLET
OIL SUCTION
SCREEN
THROTTLE
LEVER
FUEL MIXTURE
LEVER
FUEL LINE
VENT LINE
CONNECTION
DIAPHRAGM
FUEL PUMP
GROUND OR “P-LEAD” TERMINAL
OIL RETURN FROM COOLER
OIL DRAIN
PLUG
