PARTS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on
Page 30 of this manual.
KEY
NO. CATALOG NO. DESCRIPTION
VRL4543ZEN
(F1186)
VRL4543ZEP
(F1187) QTY.
1 J6564 Burner Assembly • • 1
2 J7947 Pilot, NG • 1
J8023 Pilot, LP • 1
3 J7458 Bracket, Pilot • • 1
4 J3635 Tube, Pilot • • 1
5 J8031 Cable, Spark Wire • • 4
6 J7053 Orifice, #32 • 1
J6989 Orifice, #49 • 1
7 J6819 Brass Elbow • • 1
8 J6757 Light Bulb, G9 120V/20W • • 4
9 J5207 Flat Washer • • 7
10 J4775 Bulkhead Fitting • • 1
11 J6834 Brass Elbow • • 2
12 J4714 Flextube, Dormont • • 1
13 J6694 Burner Gasket • • 2
14 J6737 Electronic Access Cover • • 1
15 J8032 Insulation, Heatshield • • 1
16 J6718 Module, Extension • • 1
17 J6570 Bracket Valve Components • • 1
18 J6738 Insulation, Heatshield • • 1
19 RP125072-03 Bracket, Battery Backup • • 1
20 J6205 Battery Backup • • 1
21 J6833 Connector, 3/8 Tube x 3/8 MPT • • 1
22 J8033 Valve, NG • 1
J8040 Valve, LP • 1
23 J7939 Control Module Skytech AF4000MOD • • 1
24 J6868 Switch, Rocker ON/OFF Remote • • 1
PARTS AVAILABLE NOT SHOWN
J6725 Clear Pebbles (6 lbs) • • 1
J6201 Wire Harness AF-400008PIN24WH2 • • 1
J6717 Main Step Wire Harness • • 1
J6719 Wire Harness Ext. AF-4000COMM12WH • • 1
J6795 Remote Transmitter • • 1
J8041 30" Flex Line • • 1
WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved
by IHP. Use of non-approved parts can result in poor performance and safety hazards.
