126861-01L
29
PARTS
BURNER ASSEMBLY
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts on
Page 30 of this manual.
WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved
by IHP. Use of non-approved parts can result in poor performance and safety hazards.
KEY
NO. CATALOG NO. DESCRIPTION
VRL4543ZEN
(F1186)
VRL4543ZEP
(F1187)
QTY.
1 J6630 Top Spacer • • 4
2 J6566 Top Nailing Flange • • 2
3 J7644 Rear Panel • • 1
4 J7877 False Door Assembly • • 1
5 J7454 Side Nailing Flange • • 4
6 J4387 Electric Duct Assembly • • 1
7 J6572 Side Face Filler • • 2
8 J6574 Access Cover Retaining Bracket • • 2
9 J6576 Access Door • • 1
10 J6720 Fireplace Hood • • 2
11 J7885 Corner Bracket • • 4
12 J6596 Side Walls • • 2
13 J6565 Pebble Pan • • 1
14 J6597 Rear Wall • • 1
