INSTALLATION Continued
Figure 5 - Framing Clearances for See-Thru Application
Ref.
Mantel
Depth Ref.
Mantel
from Top
of Opening
1 12" A 24"
2 9" B 21"
3 6" C 18"
4 4" D 16"
5 2" E 14"
A
B
C
D
E
1
2
3
4
5
Wall
Supplied firebox
hood must be
used at all times.
Note: All vertical
measurements are
from top of fireplace
hood opening to
bottom of mantel
shelf.
Noncombustible
material ma
y project
off this sur
face above
the fireb
ox hood
Figure 6 - Installing Concrete Board
Concrete
Board
Figure 4 - Framing Clearances for One Sided Application
*Please refer to overall fireplace width (Figure 8, Page 9) before
rough framing construction.
Figure 7 - Clearances for Combustible Mantels
TOP VIEW
SAFE
ZONE
Perpendicular
Wall
Combustible
Material May
Be Used
33°
8"
to Face Opening
5"
