126622-01D
17
PARTS
WOODBURNINGFIREPLACEMODELS
This list contains replaceable parts used in your fireplace.
WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved
by IHP. Use of non-approved parts can result in poor performance and safety hazards.
KEY NO. PART NO. DESCRIPTION
WRT3042RS
WRT3042RSI
WRT3042RH
WCT3042RS
WCT3042RSI
WCT3042RH
WRT3042WS
WRT3042WSI
WRT3042WH
WCT3042WS
WCT3042WSI
WCT3042WH QTY.
1 ** Insulation Pan • • • • 1
2 ** Fireplace Top • • • • 1
3 107800-01 Fireplace Surround • • • • 1
4 106642-01 Air Rod Retainer • • • • 1
5 ** Damper Rod Retainer • • • • 1
6 ** Firebox Bottom • • • • 1
7 ** Firebox Surround • • • • 1
8 ** Air Separator • • • • 1
9 See Page 18 Left Refractory • • • • 1
10 See Page 18 Right Refractory • • • • 1
11 See Page 18 Rear Refractory • • • • 1
12 See Page 18 Bottom Rear Refractory • • • • 1
13 See Page 18 Bottom Front Refractory • • • • 1
14 ** Firebox Support Leg • • • • 4
15 106687-02 DamperCanCollar • • • • 1
16 107839-01 Screen Rod • • • • 2
17 ** Firebox Top Assembly • • • • 1
18 ** Air Kit Door Assembly • • • • 1
19 ** FaceWeldment • • • • 1
20 107823-01 Smoke Deflector • • • • 1
21 ** Fireplace Top Insulation • • • • 1
22 ** Access Panel • • • • 1
23 107854-01 Right Refractory Bracket • • • • 1
24 107854-02 Left Refractory Bracket • • • • 1
25 109911-01 Grate • • • • 1
26 11418 Push-On Nut • • • • 2
27 107840-01 Stainless Screen • • • • 2
28 ** CollarInsulation • • • • 1
29 23512 ChimneyStarterCollar • • • • 1
30 20027 Refractory Retainer • • • • 2
31 20046 Grate Retainer • • • • 2
32 20088 Door Stop • • • • 1
33 20090 SpringClip • • • • 2
34 20280 Top Standoff • • • • 4
35 21171 ConduitPlateCover • • • • 4
36 24460 GasConduit • • • • 2
37 110037-01 ElectricalDuctAssembly • • • • 1
38 F1907 SS-8DM-StarterSection12"to8"DMC-42 • • • • 1
PARTS AVAILABLE NOT SHOWN
126588-02 LouverAssembly42(CirculatingModelsonly) • • 2
** Not a field replaceable part
