14
exceed an air pressure of 30 psi. Do not point the air nozzle toward yourself or
anyone else. Always wear safety glasses and a dust mask when using compressed air .
3. Replace the filter, turn the unit “ON”, and check the air flow indicator again.
4. If the air flow indicator points to “green”, the inner filter is still useable. If the
indicator points to “red”, remove the outer filter, then remove the inner filter (B)
Fig. 9C by lifting and pulling out on the bottom of the filter. DO NOT try to clean the
inner filter. It is disposable and must be r eplaced.
5. After replacing the inner filter, reinstall the outer filter .
Cleaning of the inner 3 bag filter:
The 3 bag filter is very durable. The material is multiple layers synthetic microfiber. The
synthetic microfiber builds up in non-woven layers to ensure multi-layers buildup and
eliminate fiber shedding.
This bag filter is not washable. Clean it up by compressed air periodically or by vacuum
light brush (recommended once per month). Then you can repeat to use it till it is
clogged up by the dusts and the air flow is reduced obviously. Replacement 3 bag filters
(P-610030301) are available from your retailer or from SuperMax Tools directly.
Fig. 9A
Fig. 9B
Fig. 9C
