Supermicro AOC-URG4N4-i4XTS User Manual

2-4
Super AOC-URG4N4-i4XTS, AOC-URG4N4-i2XT, and AOC-URG4N4 Add-on Card
User's Guide
Note 1: For further explanation on how to connect SlimSAS cables from
the card to the backplane, please refer to the section of the correspond-
ing motherboard/system's user manual that details the complete system
conguration. If the system user manual does not mention them, then that
system does not use SlimSAS1 and SlimSAS2.
Note 2: For this add-on card, when SlimSAS1 is used for NVMe1 and
NVMe2, each NVMe is PCIe Gen4 x4. When SlimSAS2 is used for NVMe3
and NVMe4, each NVMe is PCIe Gen4 x4.
Back of AOC-URG4N4-i4XTS, AOC-URG4N4-i2XT, and AOC-URG4N4 Layout
SLIMSAS2
SLIMSAS1
SXB3_2
SXB3_1
7
8

Supermicro AOC-URG4N4-i4XTS Specifications

General

Brand	Supermicro
Model	AOC-URG4N4-i4XTS
Category	PCI Card
Language	English
