Supermicro AOC-URG4N4-i4XTS - Major Components

Chapter 2: Hardware Components
2-5
2-2 Major Components
The following major components are installed on AOC-URG4N4-i4XTS, AOC-
URG4N4-i2XT, and AOC-URG4N4:
AOC-URG4N4-i4XTS_i2XT Major Components
No Component Name Denition
1 Intel
®
X710-TM4/
Intel
®
X710-AT2
Ethernet LAN controllers
2 JLAN1 LAN Port
3 JP2 1-2: Debug Disable (Default)
3-4: Debug Enable
4 JP3 1-2 & 3-4: 3.3V Standby On (Default)
1-3 & 2-4: 3.3V Standby OFF
5 JSFP1 Connector Cage
6 PCI-E Gen4 x 16 Slot 1
7 SlimSAS1 Cable Connector
8 SlimSAS2 Cable Connector
